Curved Blade Electric Fans GM Style 4-Blade Steel Fan COOLING
Electric fans require very little ALL30099
amperage and are suitable for use Steel 4-blade fan is a direct
in race car or tow vehicle. Fans are replacement for the popular NEW!
set up as “puller” units, mounted GM 4-blade fan. Fan features a 60
behind the radiator. By flipping degree blade design, a universal bolt pattern with
blades, reversing wires, and mounting a 5/8" pilot hole and weighs approximately 3 lbs. Small
in front of radiator, fans will operate in diameter flat washers included for proper installation.
“pusher” configuration. Each unit includes a ALL30074
mounting kit. Tech Tip:
ALL30070 ..... 10", 775 CFM This four blade fan was originally designed for use in
ALL30072 ..... 12", 925 CFM O.E. production vehicles. When this fan is used in high
ALL30074 ..... 14", 1530 CFM performance applications it is recommended that fan
ALL30076 ..... 16", 1980 CFM and mounting fasteners be inspected as a part of regular
ALL30085 .... Replacement Mounting Kit vehicle maintenance.
Economy 4-Blade Steel Fans
16" Curved Blade Steel high RPM fans are available in 15",
Electric Fan ALL30077 18" or 19". All have a universal bolt pattern
with a 5/8" pilot hole. Riveted reinforce-
An economical option to
Allstar’s standard S-blade ment plate adds strength and high
fan, this 10-blade electric fan pitch 32 degree blades increase airflow.
has many of the same features. Painted black to resist corrosion.
Universal design fan may be set up ALL30104 ..... 15" Dia.
as a puller or pusher style to mount in ALL30105 ..... 18" Dia.
front or behind the radiator. Mounting ALL30101 ..... 19" Dia.
brackets and a hardware kit are included. Fan
is 2024CFM with 21.0 amp draw and housing dimensions Fan Spacer Kits
of: 16" x 16-1/4" x 4". Fan spacers position fan closer to
radiator or fan shroud and away from
Molded Nylon Fans pulleys. 1-1/2" and larger spacers are ALL30182
uniquely designed allowing spacer to remain
Lightweight 6-blade fans are eco-
nomical and very durable. Universal bolted to water pump while changing fans.
bolt pattern with a 5/8" pilot hole. Aluminum spacers include reducer bushing,
four Allen bolts to secure spacer to water
ALL30091 ..... 14" Dia. pump and four hex bolts with
ALL30092 ..... 15" Dia. washers to secure fan to spacer.
ALL30093 ..... 16" Dia. Spacers work with 1-3/4" bolt circle
ALL30094 .... 17" Dia. ALL30186
ALL30095..... 18" Dia. flanges only.
ALL30180* ... 1/2" ALL30186...... 2"
Reinforcement Plate ALL30182* ... 1" ALL30188 ..... 2-1/2"
ALL30184 ..... 1-1/2" ALL30190...... 3"
For Nylon Fans ALL30079 ALL30192 ..... 3-1/2"
Plate installs beneath the mounting hardware ALL99027 ..... Replacement Reducer Bushing (5/8" to 3/4")
to strengthen fan mounting location and pre- *Includes one set of four bolts for fan and spacer installation.
vent hardware from damaging the fan.
Fan Freewheeler ALL30078
6-Blade Fans Lets the fan “freewheel” when extra
Heavy-duty, 27 degree 6-blade fans, avail- horsepower is needed for qualifying.
able with aluminum or steel blades, can Removal of one through-bolt disengages
move the volume of air needed to keep the fan. Fits 3/4" shafts and spaces the
race engines cool. Universal bolt fan 2.375" from the water pump.
pattern with a 5/8" pilot hole.
Replacement Parts
ALL30096 .... 15" Dia. Aluminum Blades ALL99026 ..... Replacement Bushing
ALL30097 ..... 17" Dia. Aluminum Blades
ALL30102 ..... 15" Dia. Steel Blades
ALL30103 ..... 17" Dia. Steel Blades
ALL30100 ..... 18" Dia. Steel Blades
