Page 67 - 2019 Allstar Performance Parts and Equipment Catalog
P. 67
COOLING
Radiator Honeycomb Radiator Caps
Honeycomb screen mounts to front Higher cooling system pressure raises the
of radiator to protect from rocks and boiling point of coolant to reduce the risk of
debris. Secure directly to radiator overheating. Standard size caps fit 2-1/8"
using ALL30085 mounting kit, sold O.D. x 3/4" deep necks unless otherwise ALL30129
separately. 19" x 26". noted. Recovery system caps allow coolant
ALL30158 ..... 1/2" Thick to exit the cooling system into an overflow
ALL30159 ..... 1" Thick or recovery bottle as coolant heats and
expands. As the system cools, recovery ALL30136
Universal Mounting Kit ALL30085 system caps will draw coolant back in to
keep the cooling system full. Non-recovery
Mounting kits are commonly used to mount electric fans,
oil coolers, transmission coolers or honeycomb system caps allow coolant to exit the
screen directly to a radiator. Kits include four system, but do not draw coolant back into
8" nylon mounting bolts with washers, the system. ALL30128
rubber spacer blocks and retaining Part No. Description Pressure
nuts. Bolts are pressed through the *Non-Recovery Radiator Caps
fins of the radiator to mount accessory.
ALL30134 Stant Round 18-22 PSI
ALL30135 Stant Round 21-25 PSI
Radiator Shaker Screen ALL30160
ALL30128 Stant Round 28-32 PSI
Commonly used on dirt late *Recovery System Radiator Caps
models, universal shaker ALL30132 Stant Round 16 PSI
screen is mounted in front of ALL30133 Stant Round With Lever 16 PSI
the radiator on most dirt cars.
Unit includes black powder ALL30130 Stant Round With Lever 18-22 PSI
coated aluminum frame, screen, ALL30137 Stant Octagon 21-25 PSI
1/2" x 32" cross rod, springs ALL30131 Stant Round With Lever 21-25 PSI
and retaining clips. Frame ALL30136 Round 22-24 PSI
dimensions are 17" tall and 25" wide. ALL30129 Round 29-31 PSI
ALL30138 Stant Octagon 38-42 PSI
Sprint Car Radiator Rock Screen ALL30163 *Small Diameter Recovery System Radiator Caps
ALL30124 Stant Round Small Dia. (32mm I.D., 16mm deep) 16 PSI
Aluminum rock screen helps to ALL30125 Stant Round Small Dia. (32mm I.D., 16mm deep) 19-21 PSI
protect radiators from heavy ALL30126 Stant Round Small Dia. (32mm I.D., 16mm deep) 28-32 PSI
rocks and mud. Mounting tabs *Warning: High pressure radiator caps are made for use on race vehicles only.
are integrated into the frame Do not use these caps on passenger vehicle cars with stock type radiators. It is
for quick and easy installation recommended to pressure test the complete cooling system to the maximum
to the front air box. Measures level of pressure indicated on the cap. Failure to test cooling system to the proper
pressure prior to installing the cap may result in damage to the cooling system
20-1/2" wide x 12" tall and and/or bodily injury.
weighs just under 1 lb. Quick turn springs are included.
Billet Aluminum Radiator Cap
Stainless Wire Screen ALL30139
Use screen to protect radiators, oil coolers Polished billet aluminum cover is permanently
or other items. Size referenced is the pressed onto a 16 lb. recovery style radiator
approximate opening of the screen. cap for enhanced appearance within any engine com-
partment. Cap is a suitable choice for most street driven
5/64" (.025" Wire Diameter) vehicles.
ALL22260 ..... 12" x 36"
ALL22262 ..... 36" x 36"
5/64" Radiator Tank Heating Pad ALL76420
1/8" (.035" Wire Diameter)
ALL22265 ..... 12" x 36" Fasten pad directly to the side of radiator tank to help
ALL22267 ..... 36" x 36" add heat to your engine on cool nights. 2" x 15" high
ALL22268 ..... 36" x 48" 1/8" temperature silicone heating pad externally pre-heats
coolant in the radiator and reduces overall warm up time.
3/16" (.047" Wire Diameter)
ALL22270 ..... 12" x 36" Note: Additional pads are located in the Engine section for oil pan and oil
ALL22272 ..... 36" x 36" 3/16" tank applications to add additional heat to the engine before start-up.
ALL22273 ..... 36" x 48"
