COOLING Aluminum Tank Radiators Dual Pass

Dual pass radiators circulate
Excellent quality at an affordable price. Filler necks ar e
machined, not stamped, and tanks are furnace brazed,
the radiator, then back across
not epoxied, eliminating two prime sources of leakage.
The lightweight 1" tubes, arranged in two rows, offer coolant across the top half of
the bottom half, allowing up
outstanding cooling in race cars, off-road vehicles and to twice the heat dissipation.
street machines. These radiators offer the same
features as standard Allstar
Single Pass aluminum radiators including furnace brazed ALL30035
tanks, two rows of 1" tubes, billet machined filler
1-1/2" inlets and 1-3/4" outlets
have beaded hose fittings. neck with overflow, standard 1-3/4" outlet and feature
a universal inlet design to accept fittings for a 1-1/2"
Core WxH Overall standard hose, 1-3/4" hose, -16 or -20AN fittings (sold
GM separately). Available in 24", 26", 28" and 31" overall
ALL30010 17" x 18" 22" x 19" widths (including tanks).
ALL30011 19" x 18" 24" x 19" ALL30012
ALL30012 21" x 18" 26" x 19" Core WxH Overall
ALL30014 23" x 18" 28" x 19" ALL30033 19" x 18" 24" x 19"
ALL30016 26" x 18" 31" x 19" ALL30035 21" x 18" 26" x 19"
ALL30042 23" x 15" 28" x 16" ALL30036 23" x 18" 28" x 19"
Ford ALL30037 26" x 18" 31" x 19"
ALL30020 17" x 18" 22" x 19"
ALL30021 19" x 18" 24" x 19" Triple Pass
ALL30022 21" x 18" 26" x 19"
ALL30024 23" x 18" 28" x 19" ALL30022 Triple pass radiators circulate
ALL30026 26" x 18" 31" x 19" coolant across the top portion
ALL30043 23" x 15" 28" x 16" of the radiator, back across
the mid-section and through
TECH TIP the bottom allowing max-
imum heat dissipation. These
Radiators with aluminum tanks are recommended
to use radiator caps rated at 28 lbs. or less. radiators offer the same features as
standard Allstar aluminum radiators including ALL30046
Popular Radiator Caps furnace brazed tanks, two rows of 1" tubes,
For Aluminum Tank Radiators billet machined filler neck with overflow, standard 1-3/4"
ALL30128 ..... Stant Round 28–32psi Non-Recovery ALL30128 outlet and a universal inlet designed to accept fittings for
ALL30131 ..... Stant Round With Lever 21–25psi Recovery a 1-1/2" standard hose, 1-3/4" hose, -16 or -20AN fittings
(sold separately). Available in 24", 26", 28" and 31" overall
Upper Mount Kit widths (including tanks).
For Aluminum Tank Radiators Core WxH Overall
ALL30121 ALL30045 19" x 18" 24" x 19"
ALL30046 21" x 18" 26" x 19"
Channel rests on top ALL30047 23" x 18" 28" x 19"
of the core and two ALL30048 26" x 18" 31" x 19"
flat aluminum straps
may be bolted or
welded to the channel. Hook the steel
springs into provided hole and connect Radiator Inlet Fittings
to a lower chassis location. Kit includes
channel (2" x 21.5"), two straps (1" x 11.5") and two 17" ALL30038 ..... 1-1/2" Hose Fitting ALL30038 ALL30041
springs. Fit Allstar aluminum tank radiators. ALL30041 ..... 1-3/4" Hose Fitting*
ALL30039 ..... -16AN Fitting
Replacement Parts ALL30040 .... -20AN Fitting
ALL30122 ..... Spring *Use with lower radiator hose as an upper hose
ALL30123 ..... Channel ALL30039 ALL30040

Radiator Tie Down Rods
Aluminum tie down rods are often used with an upper
radiator support to keep radiator in place. Rods have See Page 65 For A Complete Listing
3/8"-24 RH and LH threads. Often used with a Of Radiator Caps.
rod end on one or both ends.
ALL54115 ..... 20"
ALL54116 ..... 24"
ALL54117 ..... 30"
