BRAKE

DIRT RACE CAR BRAKE LINE KIT 90 DEGREE SWIVEL FITTING
Kit allows braided lines to be run throughout Black anodized aluminum fitting swivels a full 360 degrees
a dirt race car. Includes all lines needed to for convenient hose connection. 1/8"NPT fitting is commonly
reach from the calipers to inside the foot box. Due to brand used in aftermarket calipers, gauge panels or anywhere a
preference and location of pedals, master cylinders and swivel connection would be useful.
brake shut off, the specific fittings and lines to complete Part No. Description
plumbing inside the foot box area will need to be pur- ALL50108 1/8" NPT to -3AN
chased separately. ALL50109 1/8" NPT to -4AN
Concerned about brake pressure? This kit uses #3 line
with -4AN ends. The #3 line size offers a stiffer pedal feel AN UNION FITTINGS
while utilizing the more popular -4AN ends.
Black anodized aluminum flare union adapter fittings
are commonly used to connect two hoses with female AN
ends.
Part No. Description
ALL50090 -3AN to -3AN
ALL50091 -4AN to -4AN
BULKHEAD FITTINGS
Black anodized aluminum bulkhead adapter
fittings are perfect when plumbing needs to
Part No. Description ALL50092
ALL42052 Kit For Dirt Modifieds With OEM Calipers pass through a firewall, interior panel or a mounting ALL50093
ALL42053 Kit For Dirt Modifieds With Aftermarket Calipers bracket.
ALL42054 Kit For Dirt Late Models With Aftermarket Calipers Part No. Description
ALL50092 Straight -3AN to -3AN
FRONT END BRAKE LINE KIT ALL50093 Straight -4AN to -4AN
Kits include braided lines to reach from the front calipers to inside the foot ALL50094 90 Degree -3AN to -3AN
box. Braided lines are #3 size with -4AN ends. The #3 line size offers a stiffer ALL50095 90 Degree -4AN to -4AN ALL50094
pedal feel while utilizing the more popular -4AN ends. ALL50096 Tee (Run) 3AN (3x) ALL50095
ALL50097 Tee (Run) -4AN (3x)
ALL50098 -3AN Bulkhead Nut
ALL50099 -4AN Bulkhead Nut
ALL50096
ALL50097
BULKHEAD MoUNTING TAB ALL60093

1" Square 1"

Mounting Tab shown
with ALL50093
-4 Straight Bulkhead 1-11/16"
Fitting and ALL50099
Bulkhead Nut.
Part No. Description
ALL42060 Kit For Dirt Modifieds With OEM Calipers One piece steel mounting tab with 7/16" hole can be bolted to the chassis or
ALL42061 Kit For Dirt Modifieds With Aftermarket Calipers rear end to hold bulkhead fittings in place. Bracket is 5/64" thick.
ALL42062 Kit For Dirt Late Model With Aftermarket Calipers
Note: Visit our website for specific components used in these kits! RETAINER CLAMP
ALL68326
REAR END Steel clamp is designed to fit around 3" O.D. axle
BRAKE LINE KIT tube and mount other brackets or keep brackets
(SINGLE LINE DROP) in place. Lightweight clamp has 1/4" mounting
Kit is designed to eliminate “hanging” hardware and a powder coated black finish.
brake lines near the rear calipers. Rear
Brake Line Kits utilize a single line drop
located near the
left side of the
center section. From the drop, the lines tee HALF CLAMP ALL10470
and run over the top back side of the center 3" bracket can clamp to rear end axle tubes to
section, then across the backside of axle tubes neatly secure braided lines. Brackets have 3/8"
to the calipers. Braided lines are #3 line with -4AN ends. mounting holes.
Part No. Description
ALL42056 Kit For Dirt Modifieds (60" Wide) With OEM Calipers
ALL42057 Kit For Dirt Modifieds (60" Wide) With Aftermarket Calipers
ALL42058 Kit For Dirt Late Models (62" Wide) With Aftermarket Calipers
