BRAKE

PLASTIC BRAKE DUCTS PEDAL EXTENSIONS
Ducts direct outside air to brakes, oil coolers and the driver. 3" O.D. with Kits move floor mounted
centered, offset or dual outlets. pedals closer to the driver and
eliminate the need for extra
long seat brackets used to move the
driver forward. Now just leave the
seat in the desired location and move
the pedals closer to the driver.
Part No. Description
ALL42140 ALL42141 ALL42142 ALL41050 2" Kit - Complete
ALL41051 4" Kit - Complete
ALL41052 2" Master Cylinder Kit Only
ALL41053 4" Master Cylinder Kit Only
ALL41054 2" Clutch Kit Only ALL41050
ALL42143 ALL42144 ALL41055 4" Clutch Kit Only
Part No. Description
ALL42140 Centered, 5-1/2" x 8" MASTER CYLINDER
ALL42141 Offset, 5" x 9-3/4" REMOTE RESERVOIRS
ALL42142 Double Hole, 5" x 9-3/4"
ALL42143 Single Hole, Clear, 6" x 10-3/4" High-impact plastic remote reservoirs simplify brake
ALL42144 Double Hole, Clear, 9" x 11" bleeding, especially when master cylinder is mounted low in
the chassis. Available with single or dual outlet and may be
IN-LINE DUCT BLOWERS connected to master cylinder with a 5/16" hose.
Many uses include cooling brake systems or assisting helmet cooling efforts. Part No. Description
CFM ratings at 13.6 volts with a 3.5 amp draw. ALL42045 Single Outlet
ALL42046 Dual Outlet
BRAKE SHUT-OFF VALVE
ALL48010
Valve has 1/8"NPT inlet and outlet and is rated at 2,000
PSI. Use Allstar ALL50120 fitting for 3/16" inverted flare
ALL13008 ALL13009 ALL13010 brake line. Dimensions: 1/2" W x 1-3/4" L x 1-9/16" H.
Part No. Description
ALL13008 3" Heavy Duty, 8" Long, 170 CFM
ALL13009 4" Heavy Duty, 6" Long, 240 CFM PROPORTIONING VALVE ALL48025
ALL13010 3" Compact, 5" Long, 140 CFM Adjust front-to-rear brake bias with the twist of a knob.
Provides up to 57% reduction. Fitting ports are 1/8"
HANGING BRAKE NPT. Valve includes two fittings to adapt to 3/16"
PEDAL MOUNT ALL54060 brake line. 1" long, 1-3/4" wide and 3-5/16" tall.
Welds to chassis to mount Wilwood and Tilton style
hanging pedals. Notched to clear balance bar. RESIDUAL CHECK VALVES
Residual check valves hold a small
FLOOR PEDAL PLATE ALL54050 amount of pressure in the brake system
to keep the brake system functioning
properly while helping to maintain a ALL41048
firm pedal. Maintaining system pressure
prevents fluid from returning to the
master cylinder when the master cylinder ALL41049
is positioned lower than or close to the same height as the calipers or
wheel cylinders. Proper system pressure also keeps piston and wheel cylinder
seals expanded creating a positive seal and brake pads seated against the
rotor. Valves include two 3/16" inverted flare fittings.
Part No. Description
ALL41048 2 Lb. For Disc Brakes
ALL41049 10 Lb. For Drum Brakes
Weld-in pedal plate is 23" x 5" x 1/8" and speeds up race car construction by
providing the proper spacing for mounting pedal/master cylinder assemblies.
RF BRAKE SHUT-OFF VALVE DECAL
ALL48011
Use this decal to indicate if the brake shut off is in the 3
or 4 wheel brake position. Decal has a 5/8" hole and can
be applied after shut off valve is installed. Designed for use
with the ALL48010 valve or similar valves.
