BODY

SLOTTED BODY STRAP ALL23120 SPRING STEEL ALL23110
Connect and support body panels on the chassis of most Use to make braces when hanging body and
race cars. 3/16" thick x 46" long x 1" wide aluminum fender pieces. Hardened and tempered coil is
strapping has 1/4" slots every inch. Use with 40' long x 1" wide x .062" thick.
ALL23105 body brace kit for complete body
installation.
PLASTIC BODY BRACES SHRINK SLEEVE FOR SPRING STEEL
Flexible, two-piece body braces join Shrink sleeve works great when doubling up 1" wide spring
together to create one support. Braces steel.
are designed to flex as needed and
Description
Part No.
return to their original shape. ALL23112 25' Long Roll
Slotted, two-piece design allows ALL23113 100' Long Roll
brace to be adjusted from 16" to 29".
Plastic braces have reinforced ends with ACCESS PANEL KITS
aluminum inserts for 1/4" mounting bolts. Bolt with
washer and nut included for securing two halves together. Aluminum panels can be mounted to provide easy access to dry sump pump
Braces may be purchased in single piece or four-piece sets. tanks, fuel cells or other under panel items. Kits include frame, access door,
Color Single Set 4-Pc. Set hinge, quick turn fastener and quick turn fastener spring. Sizes refer to door
Black ALL23090 ALL23090-4 opening dimensions, add 2" for installed dimensions
Red ALL23092 ALL23092-4
Blue ALL23093 ALL23093-4
Yellow ALL23095 ALL23095-4
Fluorescent Orange ALL23096 ALL23096-4
Fluorescent Yellow ALL23098 ALL23098-4
Fluorescent Green ALL23099 ALL23099-4

FLEXIBLE BODY BRACE KIT ALL23080
Flexible brace attaches to body or nose panels allowing them to bend then
return to original shape, minimizing panel damage. Kit includes all components ALL18530 ALL18541
to build or assemble a flexible body brace up to 33" long with 1/4" ends that Size Clear Black
crimp to flexible rod with a standard impact crimper (ALL76135) or by using a 6" x 6" ALL18530 ALL18540
hammer and punch. 8" x 8" ALL18531 ALL18541
6" x 14" ALL18532 ALL18542
10" x 14" ALL18533 ALL18543
14" x 14" ALL18534 ALL18544
Part No. Description
Replacement Parts
ALL18990 Quick Turn Fastener, 10-Pack
ALL19300 Quick Turn Fastener Spring, 10-Pack
LUDWIG CLAMPS ALL18232
Part No. Description
Replacement Parts Clamps are used to secure access panels, deck
ALL23081 Body Brace Rod Only lids and a variety of other items in place. Zinc plated
carbon steel clamps have a 3/16" mounting hole allowing clamp to be bolted or
ALL23082 Body Brace Ends, 2-Pack riveted in place. Package of 4.
FLEXIBLE BODY BRACE ALL23075 CAR COVERS
Flexible brace made from plastic, is adjustable and can be used to support Designed for a precise fit, covers are a
lower quarter panel or nose sides.
must at the track. Asphalt version has
zippers to access the interior and at
the wheel well openings. Dirt version ALL23302
Part No. Description has zippers to access the engine area and
Replacement Part the drivers compartment. Full size covers have
ALL23076 Replacement Plastic Rod, 24" Long a soft cotton inner liner, built-in grommets,
elastic banding and are available in
SPOILER/BODY BRACE ALL23020 silver only.
Part No. Description ALL23306
ALL23300 Asphalt Late Model
(Template Body)
Mount a spoiler or use as a lower quarter panel or nose support. Adjusts from ALL23302 Dirt Late Model*
16" to 28". Sold each. ALL23306 Modified
ALL23304 Back Half Cover
* Cover is designed for cars with 8" spoiler
and sides. Cover will not fit some crate series
spoilers.
ALL23304
14
