Page 20 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog
P. 20
BUMPERS AND NOSES
BUMPER HOOKUP KIT MODIFIED REAR BUMPER KITS
ALL22315 Universal rear bumper kits have fully welded frames and include separate
Cable kit mounts through the nose and 1-1/4" O.D. mounting tubes, bumper supports and end caps that require weld-
around the bumper for easy wrecker hook- ing for a custom fit to a variety of chassis widths.
ups. Kit should be mandatory at every race track.
Kit includes 3 ft. of coated cable and two clamps.
LOWER NOSE SUPPORTS - PLASTIC
Provides support between the front
nose piece and front bumper of ALL22336
dirt late models. 38" long
supports are sold per
nose half.
Part No. Description
ALL23061 Black 3/8" Thick x 8" Wide, 3.7 lbs
ALL23063 Black 1/4" Thick x 6" Wide, 1.85 lbs
LOWER NOSE SUPPORT ALL22337
FOR MD3 EVOLUTION ALL23064
Nose support is specifically designed
to fit the inside contour of MD3
Evolution style dirt late model Part No. Description
nose. Support is just under Wide Rear Bumper Kit with straight main tube is built from
3/8" thick and measures ALL22336 1-1/4" O.D. x .065" wall mild steel tubing and measures 54"
39" wide x 7" deep wide x 11-1/2" tall with a 34" wide fuel cell guard.
at the leading edge to Narrow Rear Bumper Kit with bent main tube is built from 1-1/2"
provide plenty of mounting area to connect the nose to most bumpers. Support ALL22337 O.D. x .065" wall mild steel tubing and measures 43" wide x
fits LH or RH side and is sold per nose half. 12-1/2" tall with a 39" wide fuel cell guard.
ABC TEMPLATE FRONT BUMPERS
Designed to fit
LOWER NOSE SUPPORT - SPRING STEEL the shape of ABC
ALL23065 style nosepieces,
Provides support between bumpers are
the front nose piece and offered in welded
front bumper of dirt late and universal, un-
models. 1/16" thick x 35" welded versions.
long x 6" wide, 3.6 lbs. Welded bumper
is 1-1/2" x .065" wall and has an overall width of 48". Un-welded bumper is
1-1/2" x .083" wall and has an overall width of 58".
MODIFIED UNIVERSAL Part No. Description
FRONT BUMPER ALL22372 ABC Front Bumper Kit, Un-welded
ABC Front Bumper, Welded
ALL22376
ALL22375
Bumper has 5" x 5" plate style ASPHALT OUTLAW FRONT BUMPER
mounts which measure 44" ALL22326
from outside to outside and can be
modified to fit most chassis. Designed to mount Camaro dirt style
nose (FIV145-410) to most asphalt
late models with 34" outside frame
MODIFIED 2-PIECE EXTENDED LENGTH dimensions, including; Howe,
Finishline and Lefthander chassis.
FRONT BUMPER ALL22333
Extended length bumper fea- UNIVERSAL ASPHALT OUTLAW
tures a 1-1/2" main tube with a
1-1/4" upper hoop that can be eas- FRONT BUMPER ALL22327
ily removed and reinstalled when Universal fit bumper has adjust-
fabricating a nose. Universal fit able mounts allowing mounting of
bumper extends out 21" from frame Camaro dirt style nose (FIV145-
mounting brackets that are on 39" center and 410) or other nose pieces to most
weighs approximately 15 lbs. asphalt late models regardless of
frame width. Mounts can be positioned as
needed along main tube and then bolted or welded
in place. Commonly used on outlaw asphalt late models.
