CHASSIS

FRONT ARCH SUPPORT ALL22119 FRAME REPAIR PLATE FOR
METRIC CHASSIS ALL60085
1/8" steel rear frame plate fits 1978-88 GM
metric cars. Plate is cut to fit stock frames and
measures 4-1/4" x 27".
UNIVERSAL
SEAT MOUNT KIT ALL22110
1-1/2" dia. x .095" mild steel tubing attaches to roll
cage, to safely, effectively mount a seat. Use with Allstar
Arch supports are required when installing Allstar front support kits. They roll cage kits. Kit is sold unassembled and requires
add strength to suspension mounting area and create mounting points for welding.
shock brackets. Arches are constructed of 1-3/4", .095" wall, mild steel tubing,
24" wide at the mounting points and 16" tall but may be trimmed to fit many LOWER SEAT MOUNTS
applications. Sold each. Mounts attach through floor pan to a bar or plate on left frame rail or
roll cage for seat and anti-sub belt mounting. Layback mount
UNIVERSAL FRONT HOOP ALL22108 is raised; upright bracket has a low profile.
Part No. Description
ALL60070 Layback Seat Bracket
ALL60071 Upright Seat Bracket

SEAT MOUNT BRACKETS
Made from 1/8" thick mild steel. Upper bracket
is angled to fit against the back of most aluminum
racing seats, two-piece design allows front-to-back and ALL60032
side-to-side adjustment. Upper mount brackets may
be bolted or welded. Lower mount welds to 1-1/2" or
1-3/4" tubing.
Front support kit adds strength to the front section of race car by reducing ALL60033
excessive flex. Pre-cut and notched pieces of 1-3/4", .095" wall, mild steel Part No. Description
tubing fasten to the existing roll cage and extend to the front of the chassis to ALL60032 Upper, 2-Piece
strengthen vulnerable steering and radiator areas. Lower radiator mounting ALL60033 Lower
brackets are included. Kit requires the addition of two front arch supports
(ALL22119) sold separately to complete installation. Some modifications may DOUBLE SHEAR SEAT BELT TAB
be required for installation. ALL60031
Bracket welds to chassis for solid seat belt mount to the
UNIVERSAL REAR SUPPORT ALL22112 chassis, yet still pivot. Double shear design provides twice the
strength of a single tab style mount. Steel bracket accepts 1/2"
hardware.
FUEL CELL MOUNTING BRACKET
ALL60063
Steel bracket is radiused to fit 1-1/2" tubing and has (8) 3/8" holes
on 1/2" centers. Bracket is .085" thick and 1-1/2" wide x 4-3/4" tall.

Rear support adds strength to the rear section of race car by reducing exces-
sive flex. Kit includes pre-cut and notched pieces of 1-3/4", .095" wall, mild FUEL CELL MOUNTING BRACKETS
steel tubing which fasten to the existing roll cage and extend to the rear of the Steel brackets are .125" thick, 1-3/4" wide and available in three
chassis. Some modifications may be required for installation. lengths. All have 3/8" holes.
Part No. Description
ALL60060 2" Long
ALL60061 3" Long
ALL60062 4-3/4" Long

FUEL CELL GUARD ALL22374
Guard adds protection
to the fuel cell and acts
as a lifting point for rear
of vehicle. Universal kit
is constructed of 1-3/4",
.095 wall, mild steel tubing. Parts are pre-cut and notched, ready to be welded
together. Height is 8-3/4" and mounting width is 42".
