Page 511 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

7150 SERIES STEEL NON-ADJUSTABLE SHOCK ABSORBERS
Approved for use on IMCA Late Models or Modifieds, the 7150 series steel non-adjustable shock absorber is cost-effective, yet uses high quality damping
components to offer consistency, reliability and virtually unlimited tuning options. Shock includes an electroless nickel plated body fitted with a .500" chrome
plated steel shaft, and is offered with standard Schrader valve or an externally sealed gas valve.
Schrader Valve Ext. Sealed Gas Valve Compressed Extended Compression Rebound
Part No. Part No. Stroke Length Length Valving Valving
PENPS-7157-3/3 PENPS-7157-3/3-S 6.75" 12.75" 19.50" 3 3
PENPS-7157-3/7 PENPS-7157-3/7-S 6.75" 12.75" 19.50" 3 3
PENPS-7157-3/8 PENPS-7157-3/8-S 6.75" 12.75" 19.50" 3 8
PENPS-7157-3/10 PENPS-7157-3/10-S 6.75" 12.75" 19.50" 3 10
PENPS-7157-4/4 PENPS-7157-4/4-S 6.75" 12.75" 19.50" 4 4
PENPS-7157-5/3 PENPS-7157-5/3-S 6.75" 12.75" 19.50" 5 3
PENPS-7157-5/5 PENPS-7157-5/5-S 6.75" 12.75" 19.50" 5 5
PENPS-7159-3/3 PENPS-7159-3/3-S 8.75" 15.25" 24.00" 3 3
PENPS-7159-3/5 PENPS-7159-3/5-S 8.75" 15.25" 24.00" 3 5
PENPS-7159-3/6 PENPS-7159-3/6-S 8.75" 15.25" 24.00" 3 6
PENPS-7159-4/4 PENPS-7159-4/4-S 8.75" 15.25" 24.00" 4 4
PENPS-7159-4/6 PENPS-7159-4/6-S 8.75" 15.25" 24.00" 4 6
PENPS-7159-8/2 PENPS-7159-8/2-S 8.75" 15.25" 24.00" 8 2
PENPS-7159-8/3 PENPS-7159-8/3-S 8.75" 15.25" 24.00" 8 3
PENPS-7159-10/2 PENPS-7159-10/2-S 8.75" 15.25" 24.00" 10 2
PENKT-7155CO
SHOCK BUMP RUBBERS COIL-OVER KITS
Manufactured from micro-cell foam with ribbed wall Coil-Over Kits are designed for use with Penske
thickness for progressive rate, Shock Bump Rubbers are offered in four differ- 7150 series steel shock absorbers.
ent densities, 28, 32, 38 and 47 grams. Bump rubbers are 2.00" O.D. x 2.375" Part No. Description
tall x .060" I.D. and may be trimmed, if desired. Sold each. PENKT-7155CO 5.0" Coil-Over Kit
Part No. Description PENKT-75CO7 2.5" Coil-Over Kit
PENBR-28 28 Gram Shock Bump Rubber, Red Replacement Component
PENBR-32 32 Gram Shock Bump Rubber, White PENSR-81250 Coil-Over Spring Seat, 2.5" Dia., Flat Style
PENBR-38 38 Gram Shock Bump Rubber, Black
PENBR-47 47 Gram Shock Bump Rubber, Blue SHOCK ABSORBER ACCESSORIES
PENBR-28 Part No. Description
PENEY-7150-E100 Shock Extension, 1"
INFLATION UNIT PENEY-7150-E200 Shock Extension, 2" PENEY-7150-E100
Valve Core, 2,000 PSI
PENTL-INFLATION PENIU-04 Valve Cap, High-Temp,
Designed for use with Penske 7150 PENIU-06 For Schrader Valve Shocks
series shock absorbers. PENIU-22-S Schrader Valve
PENOR-2010-B O-Ring For Schrader Valve PENIU-22-SA

LATE MODEL/MODIFIED/CASCAR
BRAKE ROTORS
PFC’s late model/modified brake rotors are made from
superior alloys to resist cracking and are offered in smooth
ZR94 SUPER/PRO LATE MODEL or slotted designs. Directional vanes control air flow and
BRAKE PACKAGE increase brake performance and durability. Advanced pattern
The most technologically advanced caliper currently on slotted rotor enhances pad bite and reduces thermal distortion. All rotors
offered to the Late Model market. Manufactured using listed are 8-bolt with a 7" bolt circle.
a One-piece, billet aluminum four-piston calipers offer Part No. Description PFC Pad
Shape
increased pedal stiffness, improved response and less drag. PFR299-20-0045-01* LH, 11.75" Dia. x .810" Thick 0052/7752/7754
Wide 5 and 5 x 5" compatible, calipers are designed for use with PFR299-20-0045-02* RH, 11.75" Dia. x .810" Thick 0052/7752/7754
1.25" thick, 11.75-12.7" diameter discs. Calipers require PFR180-028-158-01 PFR299-32-0040-01 LH, 11.75" Dia. x 1.250" Thick 7736/7751
brackets. PFR299-32-0040-02 RH, 11.75" Dia. x 1.250" Thick 7736/7751
Piston Rotor Seal Kit PFR299-32-0045-01 LH, Late Model CASCAR, Includes Bolt Kit 0052/7752/7754
Part No. Application Size Thickness Part No. PFR299-32-0045-02 RH, Late Model CASCAR, Includes Bolt Kit 0052/7752/7754
PFR94-323-290-365-01A Left Rear/Leading Caliper 29.0/36.5mm 1.25" PFR900-900-100-05 * Includes rotor bolt kit
PFR94-323-290-365-02A Right Rear/Leading Caliper 29.0/36.5mm 1.25" PFR900-900-100-05
PFR94-323-410-440-11A Left Front/Trailing Caliper 41.0/44.0mm 1.25" PFR900-900-100-03 DDS BRAKE ROTORS
PFR94-323-410-440-12A Right Front/Trailing Caliper 41.0/44.0mm 1.25" PFR900-900-100-03 Designed for dirt late models, DDS brake rotors weigh
just 8 lbs., yet are exceptionally durable. Rotors are
RELATED COMPONENTS manufactured from superior alloys to resist cracking and
Part No. Description use directional vanes to control air flow, increase brake
PFR180-028-158-01 Caliper Bracket, Front Or Rear, Each performance and aid durability. All rotors listed are 8-bolt with
PFR195-108-080-15 V3 5x5" 5-Bolt Hub Rotor Hat, Each a 7" bolt circle.
PFR195-162-070-15 V3 Wide 5 8-Bolt Hub Rotor Hat, Each Part No. Description
PFR299-32-0040-452 V3 Rotor, 11.75" Dia. x 1.25" Thick, LH PFR295-25-0038-01 LH, 11.625" Dia. x 1.10" Thick Rotor
PFR299-32-0040-462 V3 Rotor, 11.75" Dia. x 1.25" Thick, RH PFR295-25-0038-02 RH, 11.625" Dia. x 1.10" Thick Rotor
510
