Page 513 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

PLASMA-MOLY FILE FIT PLASMA-MOLY
PISTON RING SETS STANDARD GAP
Perfect Circle Rings reduce friction, increase PISTON RING SETS
power output, reduce oil consumption and last longer. File fit sets include eight Same quality as file-fit rings, but
ductile iron plasma-moly top rings, THG (tapered hook groove) second com- ready to install. Sets are only avail-
pression rings and CP-20 oil control rings. Ring sets include standard tension able with standard tension oil rings.
oil rings unless specified. Bore Top Second Oil
Bore Top Second Oil Part No. Size Ring Ring Ring
Part No. Size Ring Ring Ring PER315-0036 4.000" 1/16" 1/16" 3/16"
PER315-0036.005 4.000" 1/16" 1/16" 3/16" PER315-0034.030 4.030" 5/64" 5/64" 3/16"
PER315-0005.005* 4.000" 1/16" 1/16" 3/16" (Low Tension) PER315-0036.030 4.030" 1/16" 1/16" 3/16"
PER315-0036.025 4.020" 1/16" 1/16" 3/16" PER315-0049.030* 4.030" 1/16" 1/16" 3mm (Low Tension)
PER315-0005.025* 4.020" 1/16" 1/16" 3/16" (Low Tension) PER315-0033.030 4.030" 1/16" 1/16" 1/8"
PER315-0034.035 4.030" 5/64" 5/64" 3/16" ‡
PER315-0036.035 4.030" 1/16" 1/16" 3/16" PER310-0014.040 4.040" 5/64" 5/64’ 3/16" (Low Tension)
PER315-0005.035* 4.030" 1/16" 1/16" 3/16" (Low Tension) PER315-0034.040 4.040" 5/64" 5/64" 3/16"
PER315-0033.035 4.030" 1/16" 1/16" 1/8" PER315-0036.040 4.040" 1/16" 1/16" 3/16"
PER310-0014.040* ‡ 4.040" 5/64" 5/64" 3/16" (Low Tension) PER315-0049.040* 4.040" 1/16" 1/16" 3mm (Low Tension)
PER315-0034.045 4.040" 5/64" 5/64" 3/16" PER315-0034.060 4.060" 5/64" 5/64" 3/16"
PER315-0036.045 4.040" 1/16" 1/16" 3/16" PER315-0036.060 4.060" 1/16" 1/16" 3/16"
PER315-0005.045* 4.040" 1/16" 1/16" 3/16" (Low Tension) PER315-0033.060 4.060" 1/16" 1/16" 1/8"
PER315-0036.065 4.060" 1/16" 1/16" 3/16" * Reduced radial wall tension. ‡ Claimer ring set.
PER315-0005.065* 4.060" 1/16" 1/16" 3/16" (Low Tension)
PER315-0005.085* 4.080" 1/16" 1/16" 3/16" (Low Tension)
PER315-0004.005* 4.125" 1/16" 1/16" 3/16" (Low Tension)
PER315-0073.005 † 4.125" 1/16" 1/16" 3/16"
PER315-0022.005 4.125" 5/64" 5/64" 3/16"
PER315-0032.005 4.125" 1/16" 1/16" 3/16"
PER315-0032.025 4.145" 1/16" 1/16" 3/16"
PER315-0004.035* 4.155" 1/16" 1/16" 3/16" (Low Tension)
PER315-0022.035 4.155" 5/64" 5/64" 3/16"
PER315-0032.035 4.155" 1/16" 1/16" 3/16"
PER315-0032.045 4.165" 1/16" 1/16" 3/16"
PER315-0032.065 4.185" 1/16" 1/16" 3/16"
* Reduced radial wall tension † Fire-Power ring set with PC479 top rings.
‡ Claimer ring set with plasma-moly cast top rings.

RYAN VANDERVEEN JOHN BERGLUND

RACING H.E.I. DISTRIBUTORS REV LIMITER DUI380777
Single-piece ignition delivers consistent, reliable perfor- Prevents engine damage from tire
mance up to 9,000 RPM. No other ignition box is needed. Dis- slippage or missed shifts. Compatible
with D.U.I. or GM HEI distributors, rev
tributor has an internal racing coil and Dyna-Module for maximum
spark energy and a customized advance curve. Distributors for GM limiter drops one cylinder at a time,
preventing fuel load-up, backfires and
602/604 crate motors have special advance curves and melonized
distributor gears for use with the steel hydraulic roller camshaft. engine damage. Set RPM limit with
plug-in RPM modules. Includes 6000,
Part No. Description
DUIL127212BK Chevy V-8, Locked-Out Advance, Black Cap 7000 and 8000 RPM modules.
DUI127212RD Chevy V-8, Red Cap
DUIS127212 Chevy V-8, “Stealth” Stock Appearing “LIVE WIRES”
DUI127212602RD Chevy “602”/”604” V-8 Crate Motor, Red Cap
DUI127212602BK Chevy “602”/”604” V-8 Crate Motor, Black Cap SPARK PLUG WIRES
DUI318211RD SB Ford 289-302, Red Cap Live Wires have a spiral wound core,
DUI358212RD SB Ford 351W, Red Cap durable silicone outer jacket and space
age, heat resistant sleeving for optimum
GM HEI DISTRIBUTOR ACCESSORIES spark travel and prevention of electronic
interference. Sleeving is effective from -76°
D.U.I. offers a full selection of high performance to +1,400° F., maintaining resistance to moisture
components for popular 1974-Up GM HEI distributors. and chemicals. Offered in red or black, plug wires DUIC9053RD
Part No. Description are custom fit with no assembly required.
Dyna-Module, Hi-Performance 4-Pin Module
DUI000222 Description Red Black
For 1974-90 GM Without Computer
Battery And Tach Connectors, SB Chevy, Under Headers, DUIC9051RD DUIC9051BK
DUI111111 HEI Distributor/90° Plug Boots
Includes (1) Terminal And (1) Connector
Racing Coil Kit, Capable Of 9,000 RPM, SB Chevy, Long, HEI Distributor/90° Plug Boots DUIC9052RD –
DUI121000RD Includes Red Cap, Rotor And Coil SB Chevy, Over Valve Covers, DUIC9053RD DUIC9053BK
DUI333333 Vacuum Advance Eliminator HEI Distributor/90° Plug Boots
DUI444444 Nylon Rotor Hold-Down Screws, Helps Prevent Misfire SB Chevy, Around Front, DUIC9054RD –
DUIR419 Racing Coil HEI Distributor/90° Plug Boots
