R4 SERIES R4 SERIES
DRY SUMP OIL PUMPS BELLHOUSING MOUNT
Innovative oil pump's four-lobe, aluminum rotor WET SUMP OIL PUMPS
offers superior flow, exceptional vacuum and Engineered to bolt directly to a Bert or
steady pressure, even at high oil tempera- Brinn bellhousing, R4 Series wet sump
tures. Weight has been minimized style oil pumps utilize a patent-pending
without compromising strength or four lobe rotor that offers consistent oil
durability through the use of profile pressure and superior flow of over 30 gallons per PTR04-1054
machined billet aluminum and a modular minute (high volume model), ideal for engines with
mounting system. The rear drive mounts to all the highest oiling demands.
power steering pumps, eliminating adapter rings. Part No. Description
All pumps listed are standard pressure.
PTR04-1054* 1-Stage Pump, Rear Drive, Standard Volume
Part No. Description PTR04-1056* 1-Stage Pump, Rear Drive, High Volume
PTR04-3000 3-Stage Pump, SB Chevy, Left Side * Signifies pump that is supplied with a KRC Rear Drive Adapter. If a KSE
PTR04-4000 4-Stage Pump, SB Chevy, Left Side pump is being used, the Rear Drive Adapter must be purchased separately;
PTR04-4020 4-Stage Pump, SB Chevy, Right Side old style KSE pump requires PTR14-2191, while new style KSE Tandem-X
pump requires PTR14-2190.
PTR04-5000 5-Stage Pump, SB Chevy, Left Side

R4 OIL PUMP MOUNT PLATES
Because gerotor gears minimize vibration, only one billet
Description Gilmer HTD aluminum plate is needed to mount Peterson R4 dry sump oil
SB Chevy Pump Installation Accessories pumps.
Oil Pump Pulley PTR06-0328 (28T) PTR06-1333 (33T) Part No. Description
Crankshaft Pulley PTR05-0216 (16T) PTR05-1219 (19T) PTR14-3100-001 Mounting Bracket For SB Chevy, Left Side
For Oil Pump Drive PTR14-3201-001 Mounting Bracket For SB Ford, Right Side
Crankshaft Pulley PTR14-3701-001 Mounting Bracket For Bellhousing
For Water Pump Drive PTR05-0221 (21T) PTR05-1225 (25T)
Belt For Oil Pump PTR05-0908 (24") PTR05-1904 (632mm) R4 REAR DRIVE ADAPTERS
Bert/Brinn Pump Installation Accessories Designed for use with R4 oil pumps, adapter allows
Oil Pump Pulley PTR06-0332 (32T) PTR06-1340 (40T) running a power steering or fuel pump off of the back
Belt For Oil Pump PTR05-0908 (24") PTR05-1905 (640mm) of the oil pump.
Pulley Flanges PTR05-0632* PTR05-1640* Part No. Description
* Sold individually, two required. PTR14-2190 Fuel Pump Adapter, KSE TandemX
PTR14-2191 KSE Power Steering Pump Adapter
R4 SERIES PTR14-2192 Power Steering Pump Adapter, PTR14-2191
BELLHOUSING MOUNT Old Style KSE
Sweet Standard
DRY SUMP OIL PUMPS PTR14-2194 Power Steering Pump
R4 Series dry sump oil pumps bolt PTR14-2195 Sweet Toyota Power Steering Pump
directly to a Bert or Brinn bellhousing.
Pumps with rear drive accept KSE
tandem pumps and Sweet power R4 OIL PUMP FITTINGS
steering pumps. All pumps listed Specialized fittings feature a special thread and use a short depth to reduce
are standard pressure, unless weight and keep a low profile. Fittings additionally utilize an internally radi-
noted. used, high flow design for maximized performance. Sold each.
Part No. Description Part No. Description
4-Stage Pump, Rear Drive, PTR14-0010 -10AN Fitting
PTR04-4056*
High Pressure PTR14-0012 -12AN Fitting
5-Stage Pump, No Rear PTR14-0016 -16AN Fitting
PTR04-5050
Drive, Std. Pressure PTR14-0020 -20AN Fitting
5-Stage Pump, Rear Drive,
PTR04-5054*
Std. Pressure R4 SERIES OIL PUMP SEAL
5-Stage Pump, Rear Drive,
PTR04-5056* PTR14-2502
High Pressure
Related Component Replacement PTFE seal for all Peterson R4 series oil pumps.
Mounting Bracket
PTR14-3701-001
For Bellhousing
* Signifies pump that is supplied with a KRC Rear Drive Adapter. If a KSE
pump is being used, the Rear Drive Adapter must be purchased separately;
old style KSE pump requires PTR14-2191, while new style KSE Tandem-X
pump requires PTR14-2190.
