Page 522 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

DRY SUMP OIL TANK ONE WAY VALVE POP OFF
MOUNTING BRACKETS PTR08-0450
Mounting brackets are machined from billet aluminum and Breather assembly is installed in valve cover on engine’s
include EPDM rubber-lined stainless steel straps. Sold in pairs. running crankcase in vacuum condition. Valve seals engine from
Part No. Description air entering engine, but opens in the event of crankcase
PTR08-0100 For 6" Dia. Tanks pressure, allowing crankcase to vent. Includes -12AN bung to
PTR08-0101 For 9" Dia. Tanks weld to aluminum valve cover.
Dirt Late Model Style,
PTR08-0106 Use On PTR08-0916, Clamps To 1-1/2" Dia. Tubing
SCREW-IN BREATHER
PTR08-0415
LIGHTWEIGHT CAP Internally baffled breather has -12AN male
AND BUNG ASSEMBLIES threads to fit bung on Peterson dry sump tanks.
Billet aluminum cap and bung assemblies are useful May also be used on valve covers.
when fabricating custom tanks. Cap is anodized red.
Part No. Description
PTR08-0611 Cap And Bung Assembly, 1-7/16" Dia.
PTR08-0621 Cap And Bung Assembly, 3" Dia. OIL PRESSURE GAUGE FITTINGS
Special fittings, designed by Karl Kinser, gets
the oil pressure gauge line up where it is more
DRY SUMP TANK FITTINGS accessible. Fitting is 1/8" NPT on engine end,
Anodized aluminum fittings complete the installation of any Peterson dry while the gauge connection is -4AN.
sump tank. Part No. Description
Part No. Description PTR15-1040 Oil Pressure Gauge Fitting, 90°
PTR08-0501 -10AN Hose x -12AN Port PTR15-1041 Oil Pressure Gauge Fitting, Straight
PTR08-0502 -12AN Hose x -12AN Port
PTR08-0503 -16AN Hose x -12AN Port OIL FILTER BLOCK OFF PLATES
PTR08-0504 -6AN Port Plug (Tank Drain) Oil filter block off plates fa cil i tate the installation of
PTR08-0505 -12AN Port Plug (Tank Drain) wet and dry sump oil pressure lines to the stock oil filter
PTR08-0506 O-Ring Kit, -12AN (5 Per Pack) pad. Plates are made from alu mi num billet and include
mount ing hard ware.
Part No. Description
REMOTE BREATHER CANS PTR09-0002 Early Chevy V-8, -12AN Fitting
Aluminum cans have internal baffling to prevent foam- With (1) 3/8"-16 Bolt Mount
ing and overflow from the dry sump tank. Mounting clamp PTR09-0004 Chevy Bow Tie Block, -12AN Fitting
is included. With (2) 5/16"-18 Bolts Mount
PTR09-0011 Ford V-8 With -12AN Fitting
Part No. Description Replacement Square O-Ring For
PTR08-0400 Spun Aluminum Tank, PTR09-0020 PTR09-0001 Thru PTR09-0004
(2) -12AN Female Ports And (1) Drain Plug
Spun Aluminum 3" Dia. Tank, Designed
To Breathe Oil Tank And Rear End, ADJUSTABLE VACUUM REGULATOR
PTR08-0410
(1) -12AN Male Fitting, (1) -8AN Male PTR08-0455
Fitting And Quick Drain Valve Billet aluminum adjustable vacuum regulator allows regulating
crankcase vacuum, which helps maximize ring seal and engine
performance. Adjustable from 2-29.7 in/hg.
OIL TANK HEAT ERS
Pre-heating of dry or wet sump sys tems SB CHEVY MANIFOLD END RAIL SPACERS
on a race engine en sures increased Fill the gap between the manifold and the lifter valley end rails when using
horsepower and good lub ri ca tion upon raised port cylinder heads on small block Chevy engines. Sold in pairs, Spacers
ini tial start-up. Im mer sion-style heater include four 3/16" roll pins for retention. Drilling of the block is required for
does a great job of pre-heat ing and only installation.
re quires weld ing a threaded bung into
Part No.
Description
the tank. Wrap around styles can be glued to the PTR09-1060 Spacer Set, .125" Thick
out side of the tank or pan. PTR09-1061 Spacer Set, .187" Thick
Part No. Description PTR09-1062 Spacer Set, .250" Thick
300 Watt Immersion Style 110 Volt With Detachable Cord Set,
PTR08-0300 PTR09-1063 Spacer Set, .375" Thick
Steel And Aluminum 1/2" NPT Weld Bungs
300 Watt Wrap Around Pad, 2" x 15", 110 Volt With Detachable
PTR08-0301
Cord Set, Attaches With Hi-Temp RTV Silicone SWIVEL WATER NECKS
400 Watt Wrap Around Pad, 4" x 10", 110 Volt With Detachable
PTR08-0302 Necks swiv el 360° for ex act hose align ment. Viton Seals
Cord Set, Attaches With Hi-Temp RTV Silicone
PTR08-0310 Replacement Cord For PTR08-1300 are used in ter nal ly and an O-ring seal is provided
300 Watt Immersion Style 220 Volt With Detachable Cord Set, on the flange. Must use a spacer with thermostat.
PTR08-1300
Steel And Aluminum 1/2" NPT Weld Bungs Part No. Description
PTR10-2116 -16AN Water Neck
PTR10-2120 -20AN Water Neck
Rebuild Kits
PTR10-2217 Rebuild Kit For -16AN Water Neck
PTR10-2221 Rebuild Kit For -20AN Water Neck
