REMOTE RELIEF VALVE HTD PULLEYS
Remote relief valve allows oil pressure to be adjusted HTD (High Torque Drive) CNC-machined aluminum Pulleys are hard-coat
where rules require that the oil pump be in the stock anodized for du ra bil i ty. Pulleys have 8mm pitch.
location. May also be used in dry sump applications to Part No. Description
make the pressure regulator more accessible. Crank Driven Pulleys – 1.020" Wide,
Part No. Description 1" Bore, 1/8" Keyway
PTR09-0160 Remote Relief Valve, -10AN Fittings PTR05-1218 18-Tooth
Remote Relief Valve, -12AN Oil PTR05-1219 19-Tooth
PTR09-0161
Fittings, -10AN Relief Line Fitting PTR05-1220 20-Tooth
PTR05-1221 21-Tooth
GILMER PUL LEYS PTR05-1222 22-Tooth
23-Tooth
PTR05-1223
Gilmer Pul leys are CNC-ma chined from billet alu mi num and hardcoated for PTR05-1225 25-Tooth
du ra bil i ty. PTR05-1233 33-Tooth
Part No. Description Oil Pump Pulleys – 1.020" Wide,
Crank Driven Pulleys – .560" Wide, 5/8" Bore, 3/16" Keyway
1" Bore, 1/8" Keyway, PTR06-1332 32-Tooth
Use with 1/2" Wide Belt PTR06-1333 33-Tooth
PTR05-0204 14-Tooth PTR06-1334 34-Tooth
PTR05-0206 16-Tooth PTR06-1335 35-Tooth
PTR05-0207 17-Tooth PTR06-1336 36-Tooth
PTR05-0208 18-Tooth PTR06-1336-W* 36-Tooth
Crank Driven Pulleys – 1.020" Wide, PTR06-1337 37-Tooth
1" Bore, 1/8" Keyway, PTR06-1338 38-Tooth
Use with 1" Wide Belt PTR06-1338-W* 38-Tooth
PTR05-0214 14-Tooth PTR06-1340 40-Tooth
PTR05-0216 16-Tooth PTR06-1340-W* 40-Tooth
PTR05-0217 17-Tooth PTR06-1344 44 Tooth
PTR05-0218 18-Tooth PTR06-1349 49-Tooth
PTR05-0219 19-Tooth Water Pump Pulleys – 2" Wide,
PTR05-0221 21-Tooth 5/8"-3/4" Bore
PTR05-0224 24-Tooth PTR05-1435 35-Tooth
PTR05-0226 26-Tooth PTR05-1437 37-Tooth
Oil Pump Pulleys – 1.020" Wide, 5/8" Splined Pulley - 1" Wide
Bore, 3/16" Keyway, PTR06-1218 18-Tooth
Use with 1" Wide Belt * 30mm (1.259" Wide) Pulley
PTR06-0324 24-Tooth HTD BELTS
PTR06-0328 28-Tooth
PTR06-0332 32-Tooth HTD (High Torque Drive) have round teeth for
PTR06-0336 36-Tooth deeper pulley engagement, making them capable
Water Pump Pulleys – 2" Wide, of withstanding more load in severe applications.
5/8"-3/4" Bore Part No. Description Part No. Description
PTR05-0428 28-Tooth 20mm Wide - 8mm Pitch 30mm Wide - 8mm Pitch
PTR05-0432 32-Tooth PTR05-1900 480mm PTR05-1931 536mm
PTR05-1901 536mm PTR05-1933 600mm
GILMER BELTS PTR05-1902 560mm PTR05-1937 632mm
Gilmer style (cog) belts are used to drive dry sump oil pumps and other PTR05-1913 592mm PTR05-1935 640mm
engine accessories. PTR05-1903 600mm PTR05-1939 656mm
608mm
PTR05-1911
Part No. Description PTR05-1908 624mm
1/2" Wide PTR05-1904 632mm
PTR05-0900 210-L-050, 21" Long PTR05-1905 640mm
PTR05-0903 225-L-050, 22.5" Long PTR05-1909 656mm
PTR05-0906 240-L-050, 24" Long PTR05-1910 680mm
PTR05-0909 255-L-050, 25.5" Long PTR05-1906 720mm
PTR05-0912 270-L-050, 27" Long PTR05-1912 760mm
PTR05-0915 285-L-050, 28.5" Long PTR05-1907 800mm
PTR05-0918 300-L-050, 30" Long PTR05-1914 840mm
PTR05-0924 322-L-050, 32.2" Long
PTR05-0960 345-L-050, 34.5" Long PULLEY FLANGES
3/4" Wide An od ized, aluminum billet flang es press into the pul ley and act as belt guides.
PTR05-0901 210-L-075 - 21" Long Flang es fit Peter son pul leys, but may not fit pul leys man u fac tured by oth er
PTR05-0904 225-L-075, 22.5" Long companies. Sold individually.
PTR05-0910 255-L-075 - 25.5" Long
Description
Part No.
PTR05-0916 285-L-07, 28.5" Long PTR05-0624 Fits 05-0324, 06-324 Pulley
PTR05-0919 300-L-075 - 30" Long
PTR05-0925 322-L-075 - 32.2" Long PTR05-0628 Fits 05-0328, 05-1334, 05-1335 Pulleys
PTR05-0632
Fits 05-0332, 06-0332 Pulley
1" Wide PTR05-0636 Fits 05-0336, 06-0336 Pulley
PTR05-0902 210-L-100, 21" Long PTR05-1632 Fits 05-1332, 06-1332 Pulley
PTR05-0905 225-L-100, 22.5" Long
PTR05-0908 240-L-100, 24" Long PTR05-1633 Fits 05-1333, 06-1333 Pulley
Fits 05-1336, 06-1336 Pulley
PTR05-1636
PTR05-0911 255-L-100, 25.5" Long PTR05-1637 Fits 05-1337, 06-1337 Pulley
PTR05-0914 270-L-100, 27" Long
PTR05-0917 285-L-100, 28.5" Long PTR05-1638 Fits 05-1338, 06-1338 Pulley
Fits 05-1340, 06-1340 Pulley
PTR05-1640
PTR05-0920 300-L-100, 30" Long
PTR05-0926 322-L-100, 32.2" Long PTR05-1644 Fits 05-1344, 06-1344 Pulley
PTR05-1649
Fits 05-1349, 06-1349 Pulley
