Page 523 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

WATER NECK RISER BLOCK INLINE BALL VALVE
Peterson’s riser blocks are avail able with two PTR09-0920
AN ports to accommodate cir cu la tion of the Inline ball shut-off valve is manufactured
water to the cyl in der heads via -6AN or -8AN from premium billet aluminum and is fitted
lines. A model with a water tem per a ture sender with a hardcoated aluminum ball and PTFE
port is also avail able. An O-ring seal is pro vid ed on seals. Valve includes -8AN inlet and outlet ports.
the flange.
Part No. Description
PTR10-2250 1" Thick Plain Riser, Accepts Thermostat GM LS7 OIL PAN ADAPTER
PTR10-2251 1" Thick Riser, Two -6AN Ports PTR15-5001
PTR10-2252 1" Thick Riser, Two -6AN Ports With Water Temp. Sender Port Special adapter allows converting to AN fittings
PTR10-2256 1-1/4" Thick Riser, Two -8AN Ports and allow compatibility with an aftermarket tank. Billet
aluminum adapter includes -12AN ports, factory seals on
Y-MANIFOLDS pan side and necessary fasteners. Port fittings must be purchased separately.
When multiple oil lines need to be combined in a single high flow line, the
tubular or billet aluminum Y-manifolds gets the job done. PTFE ENGINE SEALS
Hard-to-find PTFE engine seals assure maximum vacu-
um levels for engines with dry sump oil systems. Seals
PTR10-1725 are manufactured by TKO Competition Development.
Part No. Description
PTR10-0033 PTRSM86410 Rear Main Seal, SB Chevy 400
Part No. Description
PTR10-0030 Billet Aluminum Y-Manifold, -6, -6, -6 PTRSM86586 Jesel Front Cover, Chevy Cam Seal
PTR10-0033 Billet Aluminum Y-Manifold, -10, -8, -8 Jesel Front Cover,
PTR10-0041 Billet Aluminum 4-Way Manifold, -8, -6, -6, -6 PTRSM86587 SB Chevy Crank Seal
PTR10-1712 Aluminum Tube Y-Manifold, -12 Female, -12 Male, -12 Male PTRSM86625 Rear Main Seal, SB Chevy 350
PTR10-1721 Aluminum Tube Y-Manifold, -12, -12, -12 PTRSM86990 Front Crank Seal, SB Chevy
PTR10-1725 Aluminum Tube Y-Manifold, -16, -12, -12
FUEL PRESSURE REGULATOR FITTINGS
IN-LINE TEMP PORT ASSEMBLY Machined from aluminum, anodized fittings have large bores and are
In-line temperature sender fitting assembly has a standard radiused on the inlet sides for optimum flow.
5/8"-18 threaded port for a temperature probe.
Part No. Description Part No. Description
PTR09-1940 -10AN Nose x -10AN Nose PTR15-1002 Fuel Regulator -10AN x -8 Port
PTR09-1960 -12AN Nose x -12AN Nose PTR15-1003 Fuel Regulator -6AN x -6 Port
PTR15-1004 Fuel Regulator -8AN x -8 Port

GARRETT MARHANKA TOM WILLAVIZE JR.
MAXPROHD REVERSE BRAKE V12 REVERSE BRAKE AND CLUTCH
AND CLUTCH BLEEDER BLEEDER PHS2003-B
PHS2002HD-B The V12 reverse brake bleeding system is designed for light
New and improved, the MaxProHD duty professional use. Reverse
Reverse Brake Bleeder allows per- brake bleeder is manufactured
forming one-person brake services. from Zytel nylon that resembles
System functions by removing trapped the strength of steel. Rebuildable
air in the brake system by pushing it unit offers a virtual lifetime
up and out the master cylinder for a of use. Sold complete with
firm pedal. Die cast steel and aluminum required tubing, adapters
bodied unit features an improved check and users manual.
valve system and spring tension adjust-
ment, while optimized hydraulic ratios V5 DIY REVERSE BRAKE
provide smooth operation with minimal hand AND CLUTCH BLEEDER
force. Sold complete with required tubing,
adapters and users manual. PHS2104-B
Economical, yet powerful reverse brake
bleeding system is designed for the do-it-your-
selfer. System delivers all bleeding operations
in a small package. Sold complete with required
tubing, adapters and users manual.
