SCAVENGE FILTERS REMOTE FILTER MOUNT
Peterson’s aluminum billet Inline WITH PRIMER PUMP
Filters remove harmful debris from Reduce premature engine wear by priming the engine
the oil before it reaches the pump. before starting. Billet aluminum, remote filter mount has
The free-flowing units have twice a small pump that can provide 20 PSI in as little as 10 seconds using a standard
the filter area of dry sump pan screens. 3/8" drill. Remote filter mounts are offered to accept 1-1/2"-12 and Chevy
Part No. Description 13/16" thread oil filters and include AN fittings. Mounting brackets, in tube or
Inline Scavenge Filters flange mount versions, must be purchased separately.
PTR09-0401 -8AN, Use On Lifter Valley Scavenge Or With Rear End Pumps Part No. Description
PTR09-0402 -10AN, Use With Dry Sump Pan Or Lifter Valley Scavenge Lines Large Filter Mounts
PTR09-0403 -12AN, Use With Dry Sump Pan Lines With Primer (Accepts 1-1/2" Thread Oil Filters)
PTR09-0405 -16AN PTR09-1560 Large Filter Mount, -10AN Fittings, Left Side Primer Inlet
Inline 90° Scavenge Filters PTR09-1561 Large Filter Mount, -12AN Fittings, Left Side Primer Inlet
PTR09-0406 -8AN, Use On Lifter Valley Scavenge Or With Rear End Pumps Small Filter Mounts
PTR09-0407 -10AN, Use With Dry Sump Pan Or Lifter Valley Scavenge Lines With Primer (Accepts Chevy 13/16" Filters)
PTR09-0408 -12AN, Use On Dry Sump Pan PTR09-1501 Small Filter Mount, -10AN Fittings, Left To Right
PTR09-0409 -16AN, 90° PTR09-1502 Small Filter Mount, -12AN Fittings, Left To Right
Replacement Screens PTR09-1503 Small Filter Mount, -10AN Fittings, Right To Left
PTR09-0410 Fits PTR09-0402, PTR09-0403, PTR09-0407, PTR09-0408 PTR09-1504 Small Filter Mount, -12AN Fittings, Right To Left
PTR09-0411 Fits PTR09-0401, PTR09-0406 Mounting Brackets
PTR09-1584 Small Firewall
DRY SUMP PAN FILTERS PTR09-1590 1-1/4" Dia. Tube
Alu mi num billet filter bolts di rect ly to the pan PTR09-1592 1-1/2" Dia. Tube
fit tings and pro vides an ac ces si ble screen to PTR09-1593 1-3/4" Dia. Tube
pro tect valu able dry sump pump from in gest ing internal en gine debris. Screen PTR09-1594 Large Firewall
can easily be in spect ed with out removing pan. 2-1/4" long body. Offered in
traditional or 90° versions. DRY SUMP OIL TANKS
Part No. Description “New Generation” oil tanks are built with state-of-the-
PTR09-0404 Filter With -12AN fitting art com po nents and internal baffling, which prevents oil
PTR09-0411 Replacement Screen aeration while helping to maintain a tall column of oil over
the pick-up. Easily disassembled and tops can be ro tated
LARGE DIAMETER REMOTE FILTER MOUNT for easy placement of fittings. Brackets sold separately.
Remote filter mount is CNC machined from aircraft Part No. Description
aluminum for light weight and strength. Mount has two PTR08-0005* 2 Gal. Single Scavenge Inlet,
inlet and two outlet ports which are -12AN. Mounts 19.5" Ht. x 6" Dia.
include two AN adapter fittings and two solid PTR08-0007* 2.5 Gal. Single Scavenge Inlet,
24" Ht. x 6" Dia.
plugs. Used with Fram HP6 filter. 2.5 Gal. Dual Scavenge Inlet,
Part No. Description PTR08-0008* 24" Ht. x 6" Dia.
1-1/2"-12 Threads 3 Gal. Single Scavenge Inlet,
PTR09-1351 -10AN Fittings PTR08-0009 † 16" Ht. x 9" Dia.
PTR09-1352 -12AN Fittings † 3 Gal. Dual Scavenge Inlet,
Accessory Components PTR08-0010 16" Ht. x 9” Dia.
PTR08-0501 -10AN x -12AN Port Fitting † 4 Gal. Single Scavenge Inlet,
PTR08-0502 -12AN x -12AN Port Fitting PTR08-0011 19" Ht. x 9" Dia.
PTR08-0505 -12AN Port Plug - Solid PTR08-0025* Similar To PTR08-0005
PTR15-1010 -12AN Port Plug x 5/8"-18 Temp. Port With -12AN Male Fittings
Similar to PTR08-0007
PTR08-0027* With -12AN Male Fittings
REMOTE OIL FILTER MOUNTS Similar to PTR08-0008
Manufactured from billet, 6061-T6 aluminum for PTR08-0028* With -12AN Male Fittings
rigidity, remote mounts are offered to accept popular PTR08-0110 Replacement O-Ring For 6" Dia. Tanks
oil filters. Mounts include -12AN inlet and outlet ports, PTR08-0112 Replacement Viton O-Ring
and an 1/8" NPT gauge port. Sold complete with fittings. For 9" Dia. Tanks
Part No. Description * Use Mount Bracket PTR08-0100.
† Use Mount Bracket PTR08-0101.
PTR09-1301 Firewall Mount, Accepts 13/16" Thread Chevrolet Filter,
-10AN Fittings
Firewall Mount, Accepts 13/16" Thread Chevrolet Filter, DIRT LATE MODEL FILTER TANK
PTR09-1302
-12AN Fittings Fully redesigned tank is engineered specifically for dirt
Firewall Mount, Accepts 3/4" Thread Ford Filter,
PTR09-1312 late models, incorporates a high flow return filter located at
-12AN Fittings the bottom of the cap, allowing quick filter access. Tank in-
MOUNTING BRACKETS cludes an oil level dipstick and high flow return fittings that
Brackets fit large dia. Or remote oil filter mounts. eliminate back pressure in the return lines. Easily adapted
to an existing system, tanks are offered in 4- or 5-gallon
Part No. Description versions, include full baffling and a no mess breather design
PTR09-1584 Small Firewall for maximum oil system efficiency. Includes -16AN fittings
PTR09-1590 1-1/4" Dia. Tube
Description
Part No.
PTR09-1592 1-1/2" Dia. Tube PTR08-9016 † 4-Gallon Dry Sump Tank With Filter
PTR09-1593 1-3/4" Dia. Tube PTR08-9018 † 5-Gallon Dry Sump Tank With Filter
PTR09-1594 Large Firewall PTR09-1590 PTR19-5100 Replacement Filter
† Use Mount Bracket PTR08-0101.
