CHASSIS

Door Bar Clamp ALL14198 Narrow Front Arch Support ALL22645
Clamp fastens around a 1-1/2" NEW! Arch supports replace the front arches found on
door bar allowing a steel door many asphalt late models and modifieds or
plate to be mounted to the outside of the when fabricating a new chassis. Narrow
door bar area. Clamp eliminates the need to weld triangular design arches are constructed of
mounting tabs or door plate directly to a finished chassis. 1-3/4", .095" wall, D.O.M. steel tubing, 30"
Sold each and includes 1/2" mounting hardware. wide at the mounting points and 17" tall,
Related Items but may be trimmed to fit many applica-
ALL54070 ..... 18" x 26" Steel Plate tions. Sold as a pair*
ALL54071 .... 24" x 24" Steel Plate *LH support features a small kick out for added
ALL54072 .... 24" x 36" Steel Plate header clearance.

Steel Plate NEW! Front Arch Support
Steel plate is useful for many building ALL22119
projects or fabricating brackets. 10 Arch supports are required when
gauge (1/8" thick) 1011 mild steel installing Allstar front support kits. They
plate is ideal for adding a protective cover to the driver's add strength to suspension mounting area
side floor or door bar area of circle track cars. and create mounting points for shock
ALL54070 ..... 18" x 26" brackets. Arches are constructed of 1-3/4",
ALL54071 ..... 24" x 24" .095" wall, mild steel tubing, 24" wide at
ALL54072 ..... 24" x 36" the mounting points and 16"
tall but may be trimmed to fit
Door Plate ALL22118 many applications. Sold each.
Plates can
be welded Universal Front Hoop
between the ALL22108
drivers side door bars. May also be used to box “C”-type
frame rails to add support and strength at critical roll cage Front support kit adds strength
mounting points. Plate is 48" x 4" x 1/8" thick and man- to the front section of race car by
dated by most sanctioning bodies and tracks. reducing excessive flex. Pre-cut
and notched pieces of 1-3/4",
.095" wall, mild steel tubing
Curved Door Bar ALL22114 fasten to the existing roll cage
Curved door bar is and extend to the front of the
constructed of 1-3/4" chassis to strengthen vulnerable steering and radiator
O.D. x .095" thick areas. Lower radiator mounting brackets are included.
wall mild steel tubing and is the same door bar included in Kit requires the addition of two front arch supports
Allstar’s Standard and Deluxe roll cage kits. Bar is notched (ALL22119) sold separately to complete installa-
to fit between two vertical posts spaced 43" on center tion. Some modifications may be required
and adds approximately 6" to the width of the cage. for installation.

Universal Rear Support
Door Bar Spacers ALL22112
Spacers fit between two door bars for added support Rear support adds strength
and to equally space door bars apart. Constructed of to the rear section of race car
1-3/4" O.D. x .095" wall mild steel tubing.
by reducing excessive flex. Kit
ALL22115 ..... 4" Spacer, spaces door bars 3" apart. includes pre-cut and notched
(These bars are included in Allstar Standard and pieces of 1-3/4", .095" wall, mild
Economy Roll Cage Kits)
ALL22116 ..... 5" Spacer, spaces door bars 4" apart. steel tubing which fasten to the existing roll cage and
(These bars are included in Allstar Mini Enduro Kits) extend to the rear of the chassis. Some modifications may
be required for installation.
Swing Out Door Bar Kit ALL22670
Kit is a great starting Frame Repair Plate For
point for installation NEW! Metric Chassis ALL60085
of a swing out style door on 1/8" steel rear frame plate fits
roll bar equipped cars. Kit 1978-88 GM metric cars. Plate is cut to fit stock frames
includes (4) 2-piece mild steel and measures 4-1/4" x 27".
brackets, (4) 2" long bracket
spacers, (2) 5/16" x 2" quick
release pins, (2) 3/8"-24 x 3" hex bolts and (2) lock nuts.
www.allstarperformance.com 43
