CHASSIS Tubing Notchers Level Base ALL10741

Level base simplifies notching
Notchers render precise joints for
more consistent welds and
and helps ensure accuracy. Base fastens
stronger cages. Available
to standard ballast or weight brackets
in deluxe aluminum or and bending of round tubing
economy steel versions, and clamps to the tube as a reference
notchers accept up to 2" point when creating parallel, perpendic-
diameter stock and auto- ular, any angle of opposing notches or
matically align and center bends during fabrication. Base accepts Digital scale and
tubing. Use in drill press or most digital levels including ALL10113, mounting bracket
sold separately.
with hand drill. Notchers adjust ALL10411 ALL10742 and ALL10744 or standard
up to 45°. bubble levels.
ALL10400 ..... Deluxe Aluminum ALL10400 Individual Mounting Brackets
ALL10411 ...... Economy Steel ALL10402 ALL10403 ALL14192 ...... 1"
Replacement Parts ALL14193 ...... 1-1/4"
ALL10402 ..... 5/8"-18 Thread Adapter ALL14194 ...... 1-3/8"
ALL10403 ..... Arbor Support Bushings (Pair) ALL14195 ...... 1-1/2"
ALL10404 ..... Arbor With 1/2"-20 Thread ALL14196 ...... 1-5/8" ALL14195
Optional Parts ALL14197 ...... 1-3/4"
ALL10405 ..... Arbor With 5/8"-18 Thread ALL10406 ALL10407
ALL10406 ..... Drill Press Mount (ALL10411 Only) Deburring Tool ALL11036
ALL10407 ..... Arbor Support With Needle Bearings A fast and easy way to remove
Note: Tubing notchers include 1/2"-20 arbor thread and 5/8"-18 adapter. Hole burrs from the edges of
saws up to 1-1/8" diameter use 1/2"-20, larger hole saws use 5/8"-18 thread.
machined or cut metals.
Five-piece kit includes handle,
Hole Saw Set ALL10412 telescopic blade holder and three
Use with tubing notchers. Does not unique blades. Handle has built-in storage for blades.
include an arbor for a hand drill. Set Blade holder adjusts from 1" to 5".
includes one of each size: 3/4", 1",
1-1/8", 1-1/4", 1-1/2" 1-5/8" and 1-3/4".
Weld-On Nuts
Individual Hole Saws Weld these steel nuts into a predrilled
ALL10413 ...... 3/4" ALL10417 ...... 1-1/2" hole to provide a strong and easy method
ALL10414...... 1" ALL10418 ...... 1-5/8" of bolting brackets or accessories to chassis.
ALL10415 ...... 1-1/8" ALL10419 ...... 1-3/4" Nuts are often used when the back side of a ALL18546
ALL10416 ..... 1-1/4" fastener in not accessible and they allow quicker
Note: Hole saws up to 1-1/8" diameter use 1/2"-20 thread, larger installation and/or removal of chassis components.
hole saws use 5/8"-18 thread.
1/4"-20 Nut for 3/8" Hole
Mini Digital Level ALL10742 ALL18546 ............ (5/16" UHL), 4-Pack
Digital level with magnetic base measures the ALL18546-25 ....... (5/16" UHL), 25-Pack
angle of a single straight surface or the angle 3/8"-16 Nut for 3/4" Hole
of a joint between two straight surfaces. Displayed ALL18549 ............ Short (3/8" UHL), 4-Pack
ALL18549-25 ....... Short (3/8" UHL), 25-Pack
value on the LCD screen rotates to right side up when ALL18550 ............ Long (7/8" UHL), 4-Pack
digital level is in an upside down position. Powered by ALL18550-25 ....... Long (7/8" UHL), 25-Pack
three 3V CR2032 batteries (included). 2" x 2" x 1".
1/2"-13 Nut for 3/4" Hole
ALL18551 ............. Short (3/8" UHL), 4-Pack
Smart Tool ALL10113 ALL18551-25 ........ Short (3/8" UHL), 25-Pack
Ensure that chassis tubing is level ALL18552 ............ Long (7/8" UHL), 4-Pack
and plumb when building roll cages ALL18552-25 ....... Long (7/8" UHL), 25-Pack
or checking driveshaft angles. Also
works on trailing arms and suspension tubes when
used with ALL10740 Smart Tool Tray. A “hold” button
freezes and unfreezes readings which can be displayed as
degrees, percentages, or in./ft. at the push of a button.
Plus and minus signs indicate when pitch is more or less
than that shown on the display. Pitch reads in 1/8 in./ft.
increments. Listen and level emits an audible “beep” at
level and plumb. The tool shuts off automatically if idle
for more than six minutes. Powered by a standard 9 volt
battery. Bubba Pollard Photo: Steve Datema
