CHASSIS Tubing End Caps Remote Starter Button

Shroud Kits
Steel end caps weld to the end or
inside of tubing to provide a clean
look, prevent sharp exposed edges Kit mounts a remote starter NEW!
button directly to chassis
and seal tubes to keep out dirt and tubing. Kit includes a shroud to help
debris. Caps are commonly used on protect against accidental activation,
ends of bumpers, to fill existing holes in tab, and starter button. ALL60361
frames and as a flat gusset when butt joining
sections of square or rectangular tubing. Package of 10. ALL60360 ..... Welded Kit
ALL60361 ..... Un-welded Kit
Part No. Description Thickness
Round End Caps Battery Boxes
ALL22280 7/8" O.D. .125" Universal, lightweight steel
ALL22285 1" O.D. .125"
ALL22281 1-1/4" O.D. .125" battery boxes may be welded
ALL22286 1-3/8" O.D. .125" or bolted to the frame. Boxes
ALL22282 1-1/2" O.D. .125" are available in two sizes and
ALL22283 1-5/8" O.D. .125" include hold down hardware.
ALL22287 1-11/16" O.D. .125"
ALL22284 1-3/4" O.D. .125" ALL76100 ..... Full Size, 12" Wide x 7-1/4" Deep
Square End Caps ALL76101 ..... Short Style, 10" Wide x 7-1/4" Deep
ALL22290 1" x 1" .085"
ALL22291 1-1/2" x 1-1/2" .085" Bolt-On
ALL22292 2" x 2" .085"
Rectangle End Cap Battery Boxes
ALL22294 2" x 3" .085" Battery box has multiple 1/2"
mounting holes to bolt box directly to
Gussets the frame rail, inner fender or firewall. Box
Gussets add support and can also be fastened to round tubing using ALL76103
strength to tubing joints clamp-on ballast brackets. Constructed of 13
when building roll cages or chassis mounts. Solid, one or gauge steel, measures 11" wide x 7" deep and includes
three hole gussets are 1-7/8" tall x 1/8" thick. Reinforced 3/8" battery hold down hardware.
gussets are 2-1/8" tall x 1/8" thick with a rolled edge for ALL76102 ..... Clear Zinc
added strength. ALL76103 ..... Black
Description 10-Pack Part No. 100-Pack Part No.
Solid ALL22192 ALL22192-100 Stainless Steel Drop-Out
With One Hole ALL22194 ALL22194-100 Battery Box ALL76105
With Three Holes ALL22196 ALL22196-100
The perfect battery box where
Wrap Around Gussets battery mounts under floor. Eases
battery service and replacement. Box is
ALL22199 10-1/2" wide, 7" deep, and 9-1/2" tall and
Gussets fit 1.50" to 1.75" tubing and will accept most standard batteries.
can be used to join tubing from 70° to
110°. Wrap around style gussets are 1/16" Drag Race
thick and provide more support and rigidity than
a standard flat gusset. Sold in packs of 10. Battery Box ALL76106
Drag Race style battery box may
be welded or bolted to any chassis.
Rub Rail Flange ALL60023 Lightweight box is 7-1/4" wide x
Flanges are 3/16" thick and commonly used 10-1/4" deep, and includes hold down.
when building bolt-on style rub rails. Center hole accepts
1-1/4" tubing and has two 3/8" mounting holes spaced
2-1/4" apart. Package of 4. Upper Coil-Over
Shock Mount Kit
Charging Post Bracket ALL60230
ALL60064 Weld-in kit provides a
Securely mount Allstar charging posts mounting point for rear
on vehicles where battery is not easily accessible. coil-over shock mounts, NEW!
Predrilled holes allow quick mounting to frame or body. in tube, boxed or stock
Double-D hole design positions posts close together, but frames with up to 48" between frame rails. Great for
provides enough room for charging or jumper cable clamps. drag racing and street applications, kit includes a 48"
Charging posts sold separately. long, .120" wall x 1-1/2" mild steel tube, reinforced
mounting tabs, 2" x 3" end plates and 1/2" hardware.
