Page 57 - 2018 Allstar Performance Parts and Equipment Catalog

CHASSIS

Slider Box T-Nuts Universal Trailing Arm Brackets
T-nuts have slot built in to keep them from Brackets have three
turning. No second wrench is needed to 1/2" mounting holes
tighten or loosen. Use with ALL60186 and spaced 1-1/4" apart
ALL60188 slider box. Sold each. and may be welded
ALL60194 ..... 1/2"-13 (Coarse Thread) to 3" axle tubes to
ALL60195 ..... 1/2"-20 (Fine Thread) provide three trailing
ALL60196 ..... 5/8"-11 (Coarse Thread) arm mount locations. ALL60050 ALL60051 ALL60058
ALL60197 ..... 5/8"-18 (Fine Thread) ALL60058 is made of
ALL60192 ..... 3/4"-10 (Coarse Thread) 3/16" steel and welds to the top of the rear end housing,
ALL60193 ..... 3/4"-16 (Fine Thread) providing a point of attachment for upper trailing arms.
ALL60050 ..... Lower Bracket
Slider Box ALL60051 ..... Shock Bracket For Lower
Rod End Spacers ALL60058 ..... Upper Bracket
Spacers are machined to work
with ALL60186 and ALL60188 90/10 Shock Brackets
slider boxes fitting between ALL60026
bracket and rod end to Brackets weld to the chassis to mount a
properly space rod end and shock between the chassis and the dif-
prevent binding. May also be used as standard rod end ferential to control “unloading” during
spacers. deceleration of hard braking. 1/8" thick
ALL60187 ............ Spacers For 1/2" Slider Box, 2-Pack steel brackets fit 1-1/2" dia. tubing and
ALL60187-10 ....... Spacers For 1/2" Slider Box, 10-Pack have four 1/2" holes, spaced 1" apart. 1-pair.
ALL60189 ............ Spacers For 3/4" Slider Box, 2-Pack
ALL60189-10 ....... Spacers For 3/4" Slider Box, 10-Pack GM Metric Chassis

GM Metric Chassis Trailing Arm Bracket Kits
Trailing Arms Kits Include rear upper and lower control arm mounts.
Upper mount must be cut to desired height depending
New, stamped steel, C-channel upon where housing is located in the chassis.
arms are strong and sturdy. ALL57820
Improve handling of the rear ALL60052 ..... Kit With Single Hole Lower In Stock Location
suspension on 1978-88 GM metric ALL99282 ..... Brackets Only, 1-Pair
ALL60053 ..... Kit With Single Hole Lower, Lowered To Increase
chassis by replacing twisted or worn Traction
out trailing arms. Sold each. ALL57822 ALL99283 ..... Brackets Only, 1-Pair
ALL57820 ..... Upper, 2.6 Lbs. ALL60054 ..... Kit With Multi-Hole Lower
ALL57822 ..... Lower, 3.6 Lbs. ALL99284 ..... Brackets Only, 1-Pair

Adjustable GM
Metric Chassis ALL57824
Trailing Arms
Adjustable steel 1978-88 ALL60052
G-body metric upper and lower ALL57826 ALL99282 ALL60052
rear end trailing arms are ALL99282
complete with left
and right 3/4" rod
ends, step spacers
reducing to a 1/2" hole and cut to fit stock GM type
mounts. Upper arm aids in adjusting pinion angle and
centering rear end. Lower arm will adjust wheel base. ALL99283 ALL60053 ALL60053
ALL99283
ALL57824 ..... Upper
ALL57826 ..... Lower
Replacement Parts
ALL99320 ..... Clevis End For ALL57824
ALL99321 ..... Rod End Bushings, 2-Pack ALL99321

ALL60054
ALL99284 ALL60054
ALL99284
www.allstarperformance.com 55
