Page 58 - 2018 Allstar Performance Parts and Equipment Catalog

CHASSIS Upper Link Round Tank Brackets

(Bottle Mounts)
Chassis Brackets
Weld-on brackets have
designed to simplify tank instal-
curved 3/4" slots to Hinged brackets are uniquely
maintain pinion angle as lation and removal. Offered
the 3rd link is raised or lowered. in a wide variety of sizes to
Both brackets are notched for ALL60065 fit many applications
1-3/4" round tubing and are including NOS and fire
3/16" thick. bottles. Brackets feature
ALL60066
ALL60065 ..... Short a flat bottom with 2.5"
ALL60066..... Long bolt spacing. Use in
conjunction with chassis
Ford 9" Upper Link Brackets brackets (ALL14450-14459)
to complete your mounting
needs.
Size Polished Black
2.00" ALL14408 ALL14409
4.00" ALL14414 ALL14415
4.25" ALL14418 ALL14419
ALL60160 ALL60161
4.375" ALL14422 ALL14423
5.25" ALL14430 ALL14431
Ford 9" housing brackets
provide a mounting point for ALL60166 Neck Mount Brackets
upper link. Weld-on brackets
fit standard steel Ford Two-piece aluminum bottle
housings. mounting brackets are designed
ALL60160 ..... 1" Diameter Holes, Sold In Pairs for 1.525" diameter necks and
accept ALL14450-14459 chassis
ALL60161 ..... 1" Diameter Holes, One Required brackets.
ALL60166 ..... 3/4" Diameter Holes, Set Of 2
ALL14474 ..... Polished Bracket
Ford 9" Upper Link Brackets ALL14475 ..... Black Bracket
ALL60157 Chassis Brackets
Brackets are (Base Mounts)
designed to weld
to most Ford 9" style 2-piece brackets clamp to chassis
center sections. Steel tubing and accept round tank brackets
brackets are 3/16" (ALL14402-14431) to complete your
thick and provide mounting needs. 2.5" bolt spacing.
multiple mounting Size Polished Black
locations for 90/10 1.00" ALL14450 ALL14451
shock, upper link, 1.25" ALL14452 ALL14453
third link or pull 1.50" ALL14454 ALL14455
bar. Sold as a set. 1.625" ALL14456 ALL14457
1.725" ALL14458 ALL14459
Half Clamp Brackets Tube Clamps
Unique brackets are a must when clamping 2-piece tube clamp bolts to
completely around tubing isn’t possible. Bracket ALL10464 round tubing and provides a
clamps just over halfway around tubing and tightens to removable mount that can
create a secure mount for many accesso- be welded to for many uses.
ries. 3" bracket can clamp to rear end Clamps are constructed of 1/8"
axle tubes to neatly secure braided mild steel that is 2" wide. Includes
lines. Brackets have 3/8" mounting two 3/8" grade 8 bolts with nyloc nuts.
holes.
ALL10464 ..... 1-1/4" ALL14480 ..... 1"
ALL14481 ..... 1-1/4"
ALL10466 ..... 1-1/2" ALL14483 ..... 1-1/2"
ALL10468 ..... 1-3/4" ALL14485 ..... 1-3/4"
ALL10470 ..... 3" ALL14486 ..... 2"
ALL10470
