CHASSIS Universal Seat Mount Kit Steering Shaft Tubing

Seamless D.O.M. tubing is 3/4" O.D. with .120" wall
ALL22110
1-1/2" dia. x .095" wall mild steel tubing
a steering assembly to connect steering wheel to steering
attaches to roll cage, to safely, effec- thickness making this an excellent choice when building
tively mount a seat. Use with Allstar roll box or rack and pinion. ALL52132 oversized rod end is
cage kits. Kit is sold unassembled and commonly used to support steering shaft. Consult sanc-
requires welding. tioning rules to verify proper installation
when building a steering assembly.
Lower Seat Mounts ALL22190 ..... 5 Ft.
Mounts attach through floor ALL22191 ..... 6 Ft.
pan to a bar or plate on left
frame rail or roll cage for seat and anti-sub belt mounting. “Double D” Steering Shafts
Layback mount is raised; upright bracket has a low profile. Solid steel shaft has the appearance of two D‘s stacked
ALL60070 ..... Layback Seat Bracket back to back when viewed from the end or simply a 3/4"
ALL60071 ..... Upright Seat Bracket round shaft with flats on opposite sides. Often used with
stock type couplers, this shaft can be used in assemblies
Seat Mount Brackets without welding. Commonly connected to u-joints using a
set screw, the shaft should be dimple drilled to help pilot
Made from 1/8" thick mild steel. Upper set screws and help prevent the assembly from sliding
bracket is angled to fit against the back of ALL60032 apart. ALL52132 oversized rod end is commonly used to
most aluminum racing seats, two-piece ALL60033 support steering shaft. Consult sanctioning rules to verify
design allows front-to-back and side-to-side proper installation when building a steering assembly.
adjustment. Upper mount brackets may be bolted or
welded. Lower mount welds to 1-1/2" or 1-3/4" tubing. ALL52175 ..... 24" Shaft
ALL52176 ..... 30" Shaft
ALL60032 ..... Upper, 2-Piece ALL52177 ..... 36" Shaft
ALL60033 ..... Lower
ALL52178 ..... 60" Shaft
ALL52179 ..... 72" Shaft
Double Shear Seat Belt Tab ALL60031
Bracket welds to chassis and for solid seat belt Steering Column Brackets
mount to the chassis, yet still pivot. Double shear Stamped-steel brackets weld to dash bars to create a
design provides twice the strength of a single tab mounting point for steering shaft when using a 3/4"
style mount. Steel bracket accepts 1/2" hardware.
oversized rod end. Brackets are 3-1/8" wide and available
in a variety of lengths to fit most applica-
Floor Pedal Plate ALL54050 tions. 4" and longer brackets are pre-
notched for 1-1/2" dash bars but are
easily modified to fit other size bars.
ALL52120 ..... 2-1/2" Long
ALL52122 ..... 4" Long
ALL52124 ..... 8" Long
Weld-in pedal plate is 23" x 5" x 1/8" and speeds up ALL52126 ..... 10" Long
race car construction by providing the proper spacing for
mounting pedal/master cylinder assemblies. Clamp-On Steering Column Bracket
ALL52128
Hanging Brake Pedal Mount Aluminum bracket clamps to 1-3/4"
ALL54060 tubing and is 7-1/2" center to
Welds to chassis to mount Wilwood and center. Mounting bolts face the seat,
Tilton style hanging pedals. Notched to so the driver can easily adjust the column up and
clear balance bar. down while sitting in the seat. An oversize rod end
(sold separately, ALL 52132) mounts horizontally through
a 3/4" hole, allowing some left to right adjustment
without moving the bracket or notching the interior panel.

Steering Quickener Bracket
ALL60028
Mounts all popular steering quickeners
including AFCO, Coleman, Howe and others. Bracket has
two holes, spaced 1-3/4" apart, and may be welded to
1-1/2" or 1-3/4" dia. tubing.
