Page 89 - 2018 Allstar Performance Parts and Equipment Catalog

ENGINE

Inline Oil Temperature Tees Sprint Car Dry Sump Tank
Install in the oil return line (pump-to- Mounting Brackets
tank) to adapt a probe for an oil tem- Mounting brackets are designed
perature gauge. All inline tees have to mount 6" diameter tanks to the
1/2"NPT threads for probe fittings and left front corner of standard small block
1/4" holes for mounting. Chevy engines. Commonly mounted ALL36092
ALL90040 .... -10AN with ALL38145 sprint motor plate,
ALL90041 ..... -12AN the upper bracket utilizes the water
ALL90042..... -16AN pump mounting holes and the lower
bracket fastens to the early front engine ALL36093
Reducer Fittings mount mounting hole.
Reducer fittings are an economical way to ALL36092 ..... Upper Tank Mount
reduce the male AN thread size on items such ALL36093 ..... Lower Tank Mount
as oil coolers and inline temperature T-fitting.
ALL90075 ..... -10AN To -8AN Polished Rectangular
ALL90076 ..... -12AN To -10AN
Dry Sump Tank ALL36100
Polished Round Dry Sump Tanks Polished rectangular aluminum tank is com-
pletely washable. With removable top, three
Aluminum 6" tanks feature a -12AN male fittings (two located near the top,
highly polished finish and a one near the bottom), and two 3/8"NPT female
completely removable top to outlets (one top, one bottom). It’s perfect for use
enable thorough cleaning. on open wheel cars or even on dynamometers.
Three internal baffles are Internally baffled tank is 5" deep x 7" wide x 19"
fastened to the top for easy tall with a 10 quart capacity. Three internal baffles are drilled
removal and cleaning. All and fastened to the lid for easy removal and cleaning.
tanks have two 3/8"NPT
female ports on the top ALL36124 ..... Replacement Cap
cover for vent lines or return Immersion Heaters
lines and a 3/8" female NPT
bottom port for easy draining. ALL36101 Immersion style heater preheats
Tanks are offered in two ver- oil in wet sump oil pan or dry
sions, an AN version with a ALL36095 sump tanks to reduce overall
16AN return fitting and a 3/4"NPT female supply fitting or warm up time and improve lubrica-
an NPT version with two 3/4"NPT female ports for return tion during initial start up. 5/8" diameter stainless steel
and one 3/4"NPT female supply port. Mounting brackets sleeve inserts into pan or tank and secures with a welded
must be purchased separately. on 1/2"NPT brass screw-in fitting. 120-volt operation.
ALL76415 ..... 4-3/4" Long Heater Element w/3' Long Cord, 400W
Tank With AN Fittings ALL76416 ..... 7-1/2" Long Heater Element w/12" Long Cord, 250W
ALL36101 ..... 16" Tall, 6 Qts.*
ALL36102 ..... 18" Tall, 7 Qts.*
Heating Pads
Tank With NPT Fittings High temperature silicone
ALL36095 ..... 16" Tall, 6 Qts.* heating pads externally
ALL36096..... 18" Tall, 7 Qts.* ALL76422
preheat oil in wet sump oil
Replacement Parts pans, dry sump tanks and automatic transmission pans
ALL36124 ..... Cap reducing overall warm up time and improving lubrication
ALL99075 ..... Top O-Ring ALL36124 ALL99075 during initial start up. 3" cord, 120-volt operation.
*Capacity listed is fluid filled to approximately 4" from top of tank. ALL76420 ..... 2"x15", Self Adhesive Pad, 200W
Note: 1" of tank height equals approximately 1/2 quart of fluid.
ALL76422 ..... 5"x7", Self Adhesive Pad, 375W
ALL76424 ..... 6"x12", Velcro Strapped Pad For 6" O.D. Tanks, 435W
Round Dry Sump Tank
Mounting Kit ALL36094
Mounting with front motor
plate on left side of engine,
bracket angles outward slightly
for extra clearance, and its non-
slip material protects the tank. Mounting straps and tank
protectors are included.

James McFadden Photo: Phil Jordison
www.allstarperformance.com 87
