Page 86 - 2018 Allstar Performance Parts and Equipment Catalog
P. 86
ELECTRICAL, GAUGES & IGNITION
Low Profile Chevy Distributor CD Ignition Coil ALL81230
Hold Down ALL27505 High output ignition coil is specifically
Strong, steel hold-down clamp with designed for use with capacitive discharge
gold iridite finish fits small and big block ignition systems. 40,000 volt coil is recom-
Chevy V8 and 90° Chevy V6. Flat design pro- mended for use with Allstar Performance
vides extra distributor clearance and easy access to hold HP series distributors. Sturdy, high
down fastener. Stud and nut included. impact housing is epoxy filled to
protect against vibration. Extruded
aluminum bracket eases mounting. Mounting hardware,
Chevy Distributor Hold Down anti-vibration mounting pads, ring terminals and high
Aluminum hold-down keeps distributor temperature silicone boot are included.
secured at high RPM. Fits small or
big block Chevy V8 and 90° Chevy
V6. Stainless steel stud, nut and washer are High Output Coil ALL81232
included. Choose blue, clear or red anodized. High output coil is specifically
Description Blue Clear Red designed for use with the high output
Chevy Distributor Hold Down ALL27502 ALL27503 ALL27504 inductive storage ignition module
found in Allstar Performance
Chevy Distributor/Magneto Street/Strip series distributors.
Delivering up to 40,000 volts,
Hold Down ALL27500 this coil has a male secondary tower which offers superior
Aluminum hold down fits most boot and terminal retention and brass primary terminals
aftermarket distributors and mag- for maximum conductivity. Includes mounting hardware,
netos. An Allen head bolt prevents ring terminals and high temperature silicone boot.
distributor from turning in the clamp so
distributor can be removed and reinstalled Canister Style
without resetting the timing. Fits all Chevy V8
except 348-409. Will not fit Mallory magnetos. Ignition Coil ALL81234
45,000 high volt, oil filled coil for electronic
Iron Distributor Gears breakerless ignitions has low primary resis-
Melonized or Melonite coated gears are direct tance and 112:1 turn ratio for improved throttle
response and more power at higher rpms.
replacement for Allstar Performance and other Coil fits all standard O.E.M. brackets or Allstar
stock and performance distributors. Iron gears ALL81236 coil bracket.
are suitable for applications using high volume
oil pumps.
ALL81308 ..... 0.491" Dia. Shaft Chevy V8 Coil Mounts
ALL81309 ..... 0.500" Dia. Shaft Chevy V8 Use this lightweight, anodized
ALL81316 ..... 0.468" Dia. Shaft Ford 221-302 aluminum bracket to mount
ALL81317 ..... 0.531" Dia. Shaft Ford 351W canister type ignition coil to chassis ALL81322
ALL81318 ..... 0.531" Dia. Shaft Ford 351C, 400C/M, 429-460 quickly and securely.
ALL81320 ..... Mount For 1-1/2" Tubing
Bronze Distributor Gears ALL81322 ..... Mount For 1-3/4" Tubing
When installing a steel billet roller camshaft, ALL81324 ..... Flat Mount ALL81324
a bronze distributor gear must be installed
in place of the original cast iron gear. Gears Coil Bracket ALL81326
made of premium aluminum bronze offer high Universal coil mount for standard size
strength to withstand the stresses created by high canister style ignition coils up to 2-1/4",
pressure oil pumps. Roll pins are included. includes threaded cross bolt to aid in
ALL81310 ..... 0.491" Dia. Shaft mounting.
ALL81311 ...... 0.500" Dia. Shaft
ALL81315 ..... Replacement Distributor Gear Roll Pin LS Coil Mounting Brackets
ALL26212
LS coil mounting brackets
are black steel and sold as
a pair.
Luke Johnson Photo: Mike Reusche
84 www.allstarperformance.com
