Page 82 - 2018 Allstar Performance Parts and Equipment Catalog

ELECTRICAL, GAUGES & IGNITION

Electrical Outlets Quick Connect Battery Charging Posts
Universal outlets provide Two-piece, color-coded connectors make safe, out-of-car
remote 110v connection when connection to battery charger quick and easy. Female ends
powering block heaters, tank ALL76436 have 1/2"-20 threaded studs that connect to battery cables
heaters or other accessories and pass through a 5/8" hole in a panel up to 1/8" thick.
mounted in a race car. Outlets accept standard three Male ends of connectors fit on battery charger cables. Shafts
prong extension cords and mount directly into decking or are tapered for tight, secure connections.
to a chassis mounted bracket. ALL76432 and ALL76436 ALL76300 ..... Red
outlet kits are prewired with 5 feet of 14 AWG wiring. ALL76310 ..... Black
ALL76430 ..... Outlet ALL76301 ..... Red Female Connector Only
ALL76432 ..... Outlet w/Wiring ALL76302 ..... Red Male Connector Only
ALL76434 ..... Covered Outlet ALL76311 ..... Black Female Connector Only
ALL76436 ..... Covered Outlet w/Wiring ALL76312 ..... Black Male Connector Only
ALL76432
Brackets For Battery Charging Posts
Electrical Outlet And Quick Disconnect Mount remote charging posts through a body panel for
access to battery terminals and quick, easy, battery charging.
Steel bracket mounts to ALL60352 ALL60353 Posts have 3/8" studs and have color coded
the chassis providing caps for safety. Posts require a 1.25"
a single convenient mounting hole.
location to plug in an
electrical outlet and a ALL76139 ..... Kit (1 Red And 1 Black)
ALL76140 ..... Red Post Only
battery quick disconnect ALL76141...... Black Post Only
(ALL76320).
Electrical
ALL60352 ..... Weld-On Bracket Connectors Charging Post Bracket ALL60064
ALL60353 ..... Bolt-On Bracket Sold Separately Securely mount Allstar charging
posts on vehicles where battery
Battery is not easily accessible. Pre-drilled
Quick Disconnects holes allow quick mounting to frame
Disconnects provide a con- or body. Double-D hole design positions posts
nection for battery charging, close together, but provides enough room for charging
or for quick battery changes during a race. or jumper cable clamps. Charging posts sold separately.
Prevent accidental reverse polarity. Choose from 50 or 175 (ALL76140 and ALL76141).
amp ratings. Sold in pairs and include cable terminals.
ALL76320 ..... 50 Amp Gray Disconnects, 1-Pair GM Single Wire
ALL76322 ..... 175 Amp Red Disconnects, 1-Pair Alternators
Replacement Parts Completely remanufactured GM
ALL76321 ..... 6 Gauge Terminals For ALL76320, 1-Pair Delco single wire alternators are easily
ALL76323 ..... 2 Gauge Terminals For ALL76322, 1-Pair hooked-up. Housings are natural finish ALL80500
aluminum. Choose from 63 or 80 amp capacities.
Bracket For Quick Disconnects ALL80500..... 63 Amp, Full Size, 10.3 Lbs.
ALL60350 ALL80501 ..... 80 Amp, Compact Size, 9 Lbs.
Steel bracket mounts battery
disconnect GM Single Wire Chrome
(ALL76320) to Alternator ALL80505
the bend on the Chrome finish,single wire GM alter-
underside of deck nator with aluminum housing has a
panels found on 100 amp capacity.
late models and modifieds.

Quick Disconnect Covers
Covers install over the end of the
quick disconnects to help prevent
dirt and debris from entering the
connections. Covers have a built in
lanyard to keep the cover close to connector and for easy
assembly.
ALL76324 ..... Cover For 50 Amp Quick Disconnect
ALL76325 ..... Cover For 175 Amp Quick Disconnect
Dona Marcoullier Photo: John Berglund
80 www.allstarperformance.com
