P. 80
ELECTRICAL, GAUGES & IGNITION
Battery Boxes Plastic Battery Box
Universal, lightweight steel bat- ALL76099 NEW!
tery boxes may be welded or Two-piece battery box fits up to
bolted to the frame. Boxes group 27 size batteries and includes
are available in two sizes nylon strap with plastic mounting
and include hold down brackets. Box may be bolted through the
hardware. bottom for more permanent mounting. Cover is
ALL76100 ..... Full Size, designed with quick lock snaps to keep cover securely in
12" Wide x ALL76100 place. Outside box dimensions 16-1/8" x 9-5/8" x 10-7/8"
7-1/4" Deep tall. Inside dimensions 12-3/4" x 7-1/4" x 10" tall.
ALL76101 ..... Short Style, 10"
Wide x 7-1/4" Deep
Battery Cable Kits
Kits have everything
Bolt-On needed to connect a top
Battery Boxes post style battery to starter
and include fine stranded,
Battery box has multiple 1/2" rope-lay copper cable for ALL76110
mounting holes to bolt box best current carrying capabilities. Kits are offered with
directly to the frame rail, inner traditional red and black cables or all black cables.
fender or firewall. Box can also be
fastened to round tubing using clamp-on ALL76103 Single Battery Kits
ballast brackets. Constructed of 13 gauge ALL76110 ...... 2 Gauge Cable Kit With Red And Black Cables
steel, measures 11" wide x 7" deep and includes 3/8" bat- ALL76111 ...... 2 Gauge Cable Kit With All Black Cables
tery hold down hardware. ALL76114 ...... 4 Gauge Cable Kit With Red And Black Cables
ALL76115 ...... 4 Gauge Cable Kit With All Black Cables
ALL76102 ..... Clear Zinc
ALL76103 ..... Black Kits Include:
• 15' Positive Battery Cable • 8 Pcs. Ring Terminals
• 2' Negative Battery Cable • 8 Pcs. Heat Shrink Tubing
• 1 Pair Battery Terminals
Stainless Steel Drop-Out
Dual Battery Kits
Battery Box ALL76105 ALL76112 ...... 2 Gauge Cable Kit With Red And Black Cables
The perfect battery box where ALL76113 ...... 2 Gauge Cable Kit With All Black Cables
battery mounts under floor.
Eases battery service and replace- Kits Include:
ment. Box is 10-1/2" wide, 7" • 25' Positive Battery Cable • 14 Pcs. Ring Terminals
deep, and 9-1/2" tall and will accept • 8' Negative Battery Cable • 14 Pcs. Heat Shrink Tubing
• 2 Pair Battery Terminals
most standard batteries.
Solder Slugs
Use solder slugs to secure ring terminal ends to
Drag Race Battery Box battery cable. Individual pieces are the correct
amount of solder to be used for each size of
ALL76106 cable. Package of 10. ALL76131
Drag race style battery box may
be welded or bolted to any ALL76131...... Slug For 2 Gauge Terminals
chassis. Lightweight box is 7-1/4" ALL76132 ..... Slug For 4 Gauge Terminals
wide x 10-1/4" deep, and includes
hold down. Ring Terminals
Use to repair or build custom length
battery cables, or when installing a
battery disconnect switch. Terminals may be
Battery Hold Down Kit crimped or soldered to wire. Sold in pairs with
For Optima ALL76107 heat shrink sleeving for a waterproof connection.
Aluminum hold down kit provides Wire Size 5/16" Hole 3/8" Hole 1/2" Hole
an attractive option for keeping 2 Gauge ALL76116 ALL76117 ALL76128*
Optima 34/78 series batteries in 4 Gauge ALL76118 ALL76119 ALL76129*
place. Battery not included. *NEW!
Impact Crimper ALL76135
Excellent for permanently crimping standard
cable ends to battery cables.
