Chief Architect X10 Reference Manual

initial thickness of 1” (25 mm). See “Cabinet the ceiling; if nothing is below any wall
Defaults” on page 606. cabinets, it will fill the area between the
cabinets and the floor.
If any cabinets and/or appliances are present,
a Custom Backsplash will: • Replace the backsplash associated with
any base or wall cabinets.
• Seek to fill the area between any base
cabinets or floor appliances against that Like Wall Material Regions, Custom
wall surface and any wall cabinets and/or Backsplashes set to cut the finish layers of
windows above them. their parent object will replace the layers of
• If nothing is above any base cabinets, it the wall between itself and the wall’s Main
will fill the area between the cabinets and Layer with its own layers.

Material Region Specification Dialog

Select a Material Region or a Custom The settings in these two dialogs are also
Backsplash and click the Open found in the Material Region Defaults
Object edit button to open the Material dialogs, and most of its panels are also found
Region or Custom Backsplash in the specification dialogs for a variety of
Specification dialog. other CAD-based objects.

Material Layers Panel

• The total thickness of the Material Lay- platform or wall. When checked, it cuts
ers displays here for reference. into the finish layers of the polyline’s par-
• Click the Edit button to open the ent object and replaces those layers with
Material Layers Definition dialog. See its own within its perimeter.
“Material Layers Definition Dialogs” on
page 1001. Polyline Panel
• Uncheck Cut Finish Layers of Parent The POLYLINE panel indicates the length of
Object to fix the selected Material the region’s Perimeter and its enclosed
Region to the surface of its parent floor Area. See “Polyline Panel” on page 314.

1000
