3D View Tools



                                                                       are generated with Color toggled on when
                                    Legacy  Compatible  Texture  Mapping  the Vector View Rendering Technique is
                                    should remain unchecked except in leg-  used. See “3D View Tools” on page 1047.
                                acy plans with custom rotated textures.
                                                                       •  Select a check box to generate that view
                               •  W  h  e  n     Auto Adjust Default Glass Prop-  type in color or uncheck to generate that
                                  erties is checked, the program automati-  view type in grayscale.
                                  cally adjusts the behavior of window,   •  A colored view can always be changed to
                                  door, and electrical fixture glass in Stan-  a grayscale and vice versa by choosing
                                  dard rendered and ray trace views in    View> Color   .
                                  response to interior and exterior lighting
                                  conditions. When this box is unchecked,   4  Specify how the Surface Edge Lines
                                  these adjustments are not made.          display for all objects in 3D views.
                               •  Check Always Display Active Cameras   •  C  h  e  c  k     Use Layer Settings to display sur-
                                  to turn on the display of active camera   face edge lines for objects using the dis-
                                  symbols, even when the “Cameras” layer   play settings specified by layer in the
                                  is turned off. When unchecked, active   Layer Display Options dialog.
                                  camera symbols obey the layer setting.
                                                                          If this option is not checked, all edge
                                2   The Vector View Options only affect   lines are drawn black and solid with a
                                    views using the Vector View rendering   line weight of 0.
                               technique. See “Rendered and Vector Views”
                               on page 1042.                           •  I  f     Use Layer Settings is checked you can
                                                                          also check Use Object Settings. All
                               •  Framing Back Clip defines the back clip   objects that have special settings speci-
                                  for framing members in cross section    fied on the LINE STYLE panel of their
                                  views. Framing must be set to display to   specification dialog display using those
                                  see the effects of this value. A zero value   settings, overriding the layer settings in
                                  does not back clip at all.
                                                                          the Layer Display Options dialog.
                                3   The View Types with Color On
                                    settings control which 3D view types


                          3D View Tools

                                        Select 3D> Create                        Camera Views
                                        Orthographic View to display
                               the Orthographic View Tools or 3D> Create   Camera views are perspective views. They
                               Perspective View to display the Perspective   are not scaled and cannot be annotated but
                               View Tools.                             are ideal for creating presentation views.
                                                                            The Full Camera tool creates multi-
                                                                            floor views of the 3D model. It can be




                                                                                                      1047
