Sun Angle Specification Dialog

There are several ways to delete a sun • In floor plan view, select the Sun Angle
shadow polyline:
arrow and click the Delete Shadow
• In floor plan view, select and delete the edit button.
defining polyline.
• I n t h e Sun Angle Specification dialog,
• In floor plan view, select and delete the click the Delete Shadow button. See
Sun Angle arrow. “Earth Data Panel” on page 1101.
• I n t h e Sun Angle Specification dialog,
click the Make Shadow button to delete
existing shadows and create new ones.

Sun Angle Specification Dialog

Select CAD> Lines> Sun Angle, then To open the Sun Angle Specification dialog
click in floor plan view to open the for an existing Sun Angle, select it and click
Sun Angle Specification dialog and create a the Open Object edit button. This dialog
new Sun Angle. See “Sun Angles and can also be accessed by clicking the Edit
Shadows” on page 1098. button in Adjust Sunlight dialog. See
“Adjust Sunlight Dialog” on page 1104.

Earth Data Panel
The settings on the EARTH DATA panel let sun’s light should be calculated. This infor-
you establish exactly where your plan’s mation allows the program to generate sun-
building site is located, and exactly when the light and sun shadows with accuracy.

1101
