                                   Label Panel                  is turned on and use the Text Style assigned
                                                                to that layer. See “Text Styles” on page 519.
                        Labels for Added Lights display in floor plan
                        view when the “Light Sources, Labels” layer   For information about the settings on this
                                                                panel, see “Label Panel” on page 682.


                   Sun Angles and Shadows

                        In addition to the functional and aesthetic   If a North Pointer    is not used, north is
                        properties of ambient light and light sources   assumed to be straight up on screen in floor
                        in rendered views, the direction and angle of   plan view.
                        the sun’s light and shadows are an important
                        consideration. Two tools allow you to gener-  Select CAD> Lines> North Pointer   ,
                        ate sunlight and sun shadows with accuracy:  then click and drag to draw the pointer,
                                                                starting at the tail and dragging toward the
                        •  North Pointers    allow you to specify   point. Once it is drawn, you can define its
                           the direction of true north in a plan.
                                                                exact length and angle in its specification
                        •  Sun Angles    let you specify an exact   dialog. See “Line Specification Dialog” on
                           location, date, and time for sunlight and   page 300.
                           sun shadow generation.               Multiple North Pointers can be drawn in a
                                                                given plan file, and will always point in the
                                   North Pointer                same direction automatically. If you rotate
                             The North Pointer tool is used to   one of them, the others will automatically
                             define the direction of true north in a   rotate to match. Similarly, if you draw a new
                        plan. The direction of north does not affect   North Pointer at a different angle, existing
                        the orientation of the Snap and Reference   North Pointers will rotate to that angle
                        grids, but it does affect the direction of   automatically.
                        sunlight and sun shadows, how conditioned   If you choose to display line angles when a
                        area totals are calculated, and how bearing   North Pointer exists, be sure to select the
                        information is interpreted by the program.   appropriate format in the CAD Defaults
                                                                dialog. See “CAD Defaults and Preferences”
                             Every  bearing  is  defined  relative  to  on page 288.
                             North,  so  it  is  best  to  establish  this  •  If angles are set to Bearings, they are rel-
                         direction  before  entering  survey  information  ative to the North Pointer.
                         for  a  site  plan.  See  “Site  Plans”  on  page
                         451 of the User’s Guide.
