Chief Architect X10 Reference Manual

Setting an object’s or group of objects’ line
weight to zero causes the lines to print as The default Line Weight Scale of
thinly as possible. 1 = 1/100 mm makes it easy to meet
many professional drawing standards and in
most cases should not be changed.

Watermarks

A customizable watermark containing The method for printing a view with a
text or the image of your choice can be watermark varies depending on the view
added to any plan view or layout. To toggle type:
the watermark on or off in the current view, • For most types of views, check Show
select View> Watermark. Watermark in the Print View dialog. See
In layout files, the watermark will display on “Print View Dialog” on page 1334.
all pages; however, in plan files, watermarks • For perspective cameras and overviews,
are view specific, which means that you can toggle the watermark on before printing.
control which views include the watermark See “Saving and Printing 3D Views” on
and which do not. page 1074.
Watermarks also are file specific, so you can
have a different watermark in each plan and Note: Student, Academic, and Presentation
layout file if you wish. If you want to use a versions of the software produce a non-
particular watermark in all files, you can add editable watermark on all printed documents.
it to your plan and layout templates. See A second one can be added if you wish.
“Template Files” on page 97.

Watermark Defaults Dialog

A watermark can be customized in the When the Watermark Defaults dialog is
Watermark Defaults dialog. To open this open, the watermark will display in the view
dialog, select Edit> Default Settings and in window behind the dialog and will update as
the Default Settings dialog, click on “Water- changes are made to its settings.
mark” and click the Edit button.

1332
