Print Image Dialog

uncheck Print in Color. Lines and fill • Uncheck Update Automatically to turn
colors print as either black or white, off the print job Preview and prevent it
depending on which is closer to the line from updating as changes are made to the
or fill’s actual color. settings in this dialog.
Most black and white printers print a grey • Click the Update button to update the
scale approximation of the colors if Print in print job Preview to reflect the current
Color is selected. settings in this dialog. If Update Auto-
matically is unchecked, clicking Update
7 Advanced Options - Click the Open may force the Preview to be blank.
System Print Dialog button to close
the Print View dialog and print using your 9 When Update Automatically is
operating system’s Print dialog instead. Not checked, a preview of the current print
available when No Printer is selected. job displays here. The drawing sheet displays
as a white rectangle, and if multiple sheets
8 Control the appearance of the print job are required, you can scroll through them. If
Preview on the right side of the dialog. the print job is large, a progress dialog may
• Specify the Page that displays in the Pre- display briefly as the preview draws or
view area. updates.
• Click the buttons to Zoom In, Zoom To help prevent unwanted printed
Out, or Fit the selected Page to the 10 output, information messages regarding
extents of the Preview area. page size, resolution, and scale may display
here, depending on the settings in this dialog.

Print Image Dialog

Any view can be printed by selecting The Print Image dialog is similar to the Print
File> Print Image. This is the only View dialog; however, the printing process is
way to print a Ray Trace or most 3D views. different. Print Image prints individual
See “3D Rendering” on page 1087. pixels as opposed to vectors (lines).
