Cabinet Fillers

• Front fixtures can only be modified or Storage and Organization
deleted in the Cabinet Specification dia- Inserts
log. See “Front/Sides/Back Panel” on
page 632. Rollout organizing and storage items can be
specified for any Door or Opening front item
When a cabinet has a fixture on either its top in the Cabinet Shelf Specification dialog.
or front, the Open Symbol edit button See “Rollout Shelves and Storage” on page
opens its specification dialog. When a 616.
cabinet has both, the Open Symbol Inserts for drawers and the backs of doors
button opens the specification dialog for the can be specified in the Door and Drawer
fixture on the front. When a cabinet has Face Item Specification dialogs. See “Door/
multiple front appliances, the Open Drawer Panel” on page 636.
Symbol edit button will not be available.
Electrical Switches and Outlets
Fixtures can be added to both the top Electrical switches and outlets can be
and front of the same cabinet. It is up to placed on cabinets in most views. See
you to determine which can be effectively and “The Electrical Tools” on page 651.
safely combined in the real world.

Cabinet Fillers

Cabinet fillers can be created automatically a filler in the angle between them. A filler is
or placed manually. See “General Cabinet used to separate the front of one of these
Defaults” on page 607. cabinets from the one it meets so that
drawers and doors have room to operate.
Both automatic and manually placed cabinet
fillers are included in the Materials List.
Cabinet filler sizes in the Materials List are
rounded to the nearest 1/16” (1 mm).

Automatic Fillers

By default, Chief Architect models a
continuous countertop and generates fillers Two base cabinets and the filler between them
automatically when cabinets of the same
height are either touching or placed with 3” You can specify whether these automatic
(75 mm) of one another. fillers generate in both situations the General
Cabinet Defaults dialog. See “General
If two cabinets meeting at a corner are Cabinet Defaults” on page 607.
separated from each other by 3” (75 mm) or
less, the program will automatically generate

611
