Chief Architect X10 Reference Manual

point of the cabinet’s front is visible in the open each is drawn. See “Front/Sides/Back
view. See “Cabinet Labels” on page 617. Panel” on page 632.

To show door opening indicator arrows in By default, doors and drawers do not display
cross section/elevation and Orthographic in floor plan view when they are closed- even
views, turn on the “Opening Indicators” when the “Cabinets, Doors & Drawers” layer
layer. Opening indicators display in Vector is set to display. You can, however, check
Views only. See “Vector View” on page Show Closed Doors/Drawers in Plan
1106. Views in the General Cabinet Defaults dia-
log. See “General Cabinet Defaults” on page
Cabinet Doors and Drawers 607.
There are several options for controlling the Rollout Shelves and Storage
display of cabinet doors and drawers in floor
plan and 3D views. Shelves can be specified for Door and Open-
ing cabinet front items and are visible in 3D
Cabinet doors and drawers are drawn on the views. Those inside of Doors will display in
“Cabinets, Doors & Drawers” layer. In floor 3D views only when Doors and Rollout
plan view, they use the line style, color, and Shelves are set to Show Open. See “Front/
weight assigned to that layer when they are Sides/Back Panel” on page 632.
set to display. In 3D Vector Views, they use
the line style, color, and weight assigned to Shelves can be specified as Rollout, each
their parent cabinet’s layer. with its own rollout percentage, and will
display in 3D views when Doors and Rollout
Cabinet doors and drawers can be drawn Shelves are set to Show Open. If a Rollout
open or closed in both floor plan and 3D shelf is in an a Door item, the door must be
views.
set to 100% Percent Open in order for the
• To draw a selected cabinet’s doors open shelf to draw open. See “Cabinet Shelf
in all views, click the Open Cabinet Specification Dialog” on page 641.
Doors edit button. Any shelves set as Cabinet shelves and added storage items do
Rollout will display in 3D views as well. not display in floor plan view.
• To draw its drawers open in all views,
In the Materials List
click the Open Cabinet Drawers
edit button. The materials associated with cabinet objects
• To close the doors and/or drawers, click are listed under different Categories in the
Materials List:
the Close Cabinet Doors o r Close
• Cabinets - Lists Cabinets, Shelves, Parti-
Cabinet Drawers edit button.
tions, Custom Countertops, Custom
Cabinet doors and drawers also can be set to Backsplashes, Cabinet Fillers, and cabi-
Show Open in the Cabinet Specification net doors and drawers placed indepen-
dialog. In addition, you can specify how far dently from the library.

616
