Chief Architect X10 Reference Manual

• User-Specified, which are entered in the B Base
Cabinet Specification dialog. See OB Oven Base
“Label Panel” on page 682. SB Sink Base
• Schedule Callout Labels, which are RB Range Base
specified in the Cabinet Schedule #DB Drawer Bank (# is the
Specification dialog. See “Label Panel” number of drawers
on page 679. FHB Full Height Base (1 full
height door
The minimum on-screen display size of
object labels can be specified in the W Wall
Preferences dialog. See “Appearance Code from Drawer (# is the number
Panel” on page 105. above + #D of drawers

Automatic Labels U Full Height (Utility)

The format for automatic cabinet labels has OTC Tall Oven
four parts: Key, Code, Size, and Door Swing. RTC Tall Refrigerator
The Key provides basic information about Blind corner cabinets are dependent on the
the cabinet box and its use. B refers to base cabinet’s position in the plan. A cabinet can
cabinets, W refers to wall cabinets and U only be a blind corner cabinet when its front
refers to full height cabinets.
is partially hidden by another cabinet. See
Together with the key, the Code provides “Blind Cabinets” on page 627. If a cabinet is
additional information about the shape of the moved, therefore, its Code information may
cabinet box: change.
Peninsula cabinets are only designated as
Code such when they have one or more doors on
All Cabinets the back side. See “Front/Sides/Back Panel”
LS + Key Lazy Susan on page 632.
LSD + Key Lazy Susan Diagonal Door
DC + Key Diagonal Door The Size follows the Code in a cabinet label.
LC + Key Left Corner Cabinet width is always included in the label;
BC + Key Blind Corner depth and height, on the other hand, may be
included depending on the cabinet type and
PBC + Key Peninsula Blind Corner whether they are standard or non-standard.
Key + P Peninsula
Key + F Filler Base and full height cabinet labels present
E + Key Right or Left End Size information in this order: width, depth,
A + Key Angled Front height. Wall cabinet labels present it in a
PR + Key Peninsula Radius slightly different order: width, height, depth.
R + Key Radius End

618
