Chief Architect X10 Reference Manual

Cabinet Shelves You can also specify the material assigned to
a cabinet’s shelves on the MATERIALS panel
You can customize the shelves inside of base, of the Cabinet Specification dialog. See
wall, and full height cabinet boxes. See “Cabinet Specification Dialog” on page 627.
“Cabinet Shelf Specification Dialog” on
page 641.

Special Cabinets

There are a number of special cabinet shapes either the Base Cabinet , Wall Cabinet
that can be specified. Certain requirements
must be met before some special cabinet , or Full Height cabinet tool. A
shapes can be specified. If the requirements corner cabinet remains a corner cabinet when
are not met, a warning message will explain it is moved, edited or copied.
what is needed. See “Cabinet Specification You can turn an existing cabinet into a corner
Dialog” on page 627. cabinet by selecting “Corner” from the
Special drop-down list in its specification
Note: Only Standard cabinets can be the dialog. See “General Panel” on page 628.
default cabinet Type. See “Cabinet Defaults” • Before a corner cabinet can be specified
on page 606.
in the Cabinet Specification dialog, the
Standard Cabinets cabinet’s Width must be greater than its
Depth.
Select Build> Cabinet> Base Cabinet • The Left and the Right Side Widths can
and click in floor plan view to place a be set independently for corner cabinets.
standard, rectangular base cabinet.

Corner cabinet with sides of equal width
Standard (default) cabinet
• You can specify a Diagonal Door on cor-
Corner Cabinets ner cabinets to create an angled corner
cabinet. See “Front/Sides/Back Panel” on
To create a corner cabinet, click as close to
an inside wall corner as possible in using page 632.

624
