Cabinet Specification Dialog

so that they are not located in the hidden
portion of the cabinet face.

Correct - Incorrect -
Widths of front and Solid line here is not
back cabinets match suppressed.
You can turn off this automatic behavior in
Blind Cabinets the General Cabinet Defaults dialog. See
Often, when two cabinets meet in a corner, “General Cabinet Defaults” on page 607.
one is partially hidden by the other. This You can also create a blind cabinet manually
partially hidden cabinet is called a “blind” by controlling the widths of a cabinet’s left or
cabinet. Chief Architect will resize and offset right stile in its Cabinet Specification
the front items of the partially hidden cabinet dialog. See “Front/Sides/Back Panel” on
page 632.

Cabinet Specification Dialog
Select one or more cabinet and click opens instead and has fewer options than the
the Open Object edit button to open Cabinet Specification dialog. See “Symbol
the Cabinet Specification dialog. Specification Dialog” on page 951.
You can also open the specification dialog The options in the Cabinet Specification
for the cabinet(s) associated with a schedule dialogs are similar to the corresponding
row. See “Open Row Object(s)” on page 670. Cabinet Defaults dialog. See “Cabinet
Defaults” on page 606.
If the selected cabinet is an imported symbol,
the Cabinet Symbol Specification dialog

627
