Cabinet Specification Dialog

Box Construction Panel

1 Define the Box Construction of the The Vertical Overlap is the distance that
selected cabinet. Select Framed to doors and drawers overlap the horizontal
create a traditional framed cabinet and enable separations between front items and is
the settings below, or choose Frameless for a applied to both the top and bottom of the
European style cabinet. doors and drawers.
• Specify the Separation value, which is • Select Full Overlay, then specify the
the width of the horizontal face frame Reveal, which is the distance between
piece between doors, drawers, and other door and drawer front items.
face items. • Select Inset to produce doors and draw-

2 Define the Door/Drawer Overlay of ers that are flush with the rails and stiles
the selected cabinet. rather than overlaying it.
• Select Traditional Overlay, then specify 3 Cabinet Corner Treatment - Specify
the Side and Vertical Overlap values. clipped or rounded corners for the
selected cabinet’s box. These settings are
The Side Overlap is the distance that only available for Standard, Corner, and Bow
doors and drawers overlap the vertical Front cabinet types.
stiles of the cabinet box and is applied to • Select Rounded to create rounded cabi-
both sides of the doors and drawers. net corners, then specify the length of the
chords of those rounded corners.
