Cabinet Specification Dialog

1 Select which Cabinet Side you would list can be navigated using the arrow and
like to edit: the Front, Back, Left or number keys. The vertical frame pieces on
Right side. the sides of the cabinet front are referred to
• Assign a Side Type to the selected Side. as stiles and cannot be selected in the
Only “Use Default” and “Custom Face” preview. See “Cabinet Face Items” on page
are available for the Front. The options 621.
are: • A numbered tree list of face items dis-
• Select “Use Default” to use the default plays here. Item numbers start at the top
configuration set in the Cabinet Defaults of the cabinet and go down the face to the
dialog. See “Cabinet Defaults” on page bottom of the cabinet. Item 1 is usually
606. the top face frame Separation, or rail. The
selected face item is highlighted; if no
• Select “Finished” to specify the selected item is selected, the “Vertical Layout Par-
side as finished or “Unfinished” to spec- ent” heading will be highlighted.
ify it as unfinished.”Finished” and
“Unfinished” are only used in Cabinet • C l i c k Add New to add a new face item
Schedules. See “Columns and Objects to directly below the currently selected
Include” on page 672. item. When a face item is added, the
height of the lowest item on the cabinet
• Select “Auto Finished” to finish the side front is reduced to make room for the
only when it is not adjacent to another new item. If you click Add New with no
cabinet or a wall. face item selected, the new item is added
• Select “Paneled” to apply a panel to the to the bottom of the cabinet face.
selected side. • I n t h e New Cabinet Face Item dialog,
• Select “Auto Paneled” to apply a panel to define the Item Type, Item Height, and
the side only when it is not adjacent to click OK. If the Item Type is “Separa-
another cabinet or a wall. tion”, you can check Default to use the
• Select “Match Front” to apply the same default Separation Height.
face items as the cabinet front to the
selected side.
• Select “Custom Face” to enable the Face
Items settings below.

2 Most of the Face Items settings are
only active when a door, drawer, or
other face item is selected. • C l i c k Delete to remove the selected face
item. When an Auto Left, Auto Right,
To select a face item, click on its name in the Left, Right, or Double Door is deleted, it
list or click on it in the preview on the right. is replaced by an Opening; when other
When a face item is selected, it is face item types are deleted, the height of
highlighted in the list as well as in the the lowest item is increased to make up
preview; its attributes can be edited; and the

633
