Chief Architect X10 Reference Manual

stile. Other face items types are not the drawer face; or Two Handles In
affected by this setting. From Edge for two handles set in from
the drawer sides by the value specified in
2 Specify the characteristics of the the text field.
selected cabinet’s Door Handles.
• Specify the Vertical Position of the
• Select a door handle Style from the drop- drawer handle(s): Choose Use Default to
down list or choose one from the use the default position, Centered for
Library.
handle(s) centered on the drawer face, or
• Specify the position of the handle In specify the handle’s Distance From Top.
From Edge, as measured from the edge
of the door opposite the hinges. 6 Options -
• Specify the height of the handle Down
From Top, as measured from the top • Enter a Slab Bevel width to create bev-
edge of the door. For wall cabinets, this eled edges on Slab drawers and doors.
value is measured Up From Bottom. The bevel width, as viewed from the
front, has a maximum value of 3” (75
3 Specify the characteristics of the mm). Framed and Library doors are not
cabinet Door Hinges. affected by this setting.
• Select a door hinge Style from the drop- A preview of the selected cabinet
down list or choose one from the 7 displays on the right side of the panel.
Library. See “Dialog Preview Panes” on page 42.
• Specify the location of the hinges Up/ • The cabinet Label displays below the
Down From Edge, as measured from the preview pane. See “Cabinet Labels” on
door edge. If the cabinet door is more page 617.
than 35 1/4” (880 mm) high, three hinges
will be created instead of two. Door and Drawer Face Item

4 Select a Drawer Style from the drop- Specification Dialogs
down list or choose one from the
Library. For best results, “Framed” drawers Additional settings are available in the Door
should be at least 6” (150 mm) high. and Drawer Face Item Specification
dialogs. See “Storage and Organization
5 Specify the characteristics of the Inserts” on page 611.
selected cabinet’s Drawer Handles.
The Door Back Inserts settings allow you to
• Select a drawer Handle Style from the choose one or more storage items for the
drop-down list or choose one from the back of a selected door.
Library.
• A drop-down list of the inserts assigned to
• Specify the Horizontal Position of the the selected door displays here. Select the
drawer handle(s): Choose Use Default to name of an object to edit it or remove it
use the default position; One Handle from the list.
Centered for a single handle centered on

638
