Chief Architect X10 Reference Manual

the difference. You can also press the • Click Equalize to make the sizes of a
Delete key on the keyboard. face item’s sub-items equal in size. Only
available if the selected item is a Vertical
The program tries to maintain a single or Horizontal Layout with sub-items.
separation between all face items. • Choose the selected face item’s Item
When you add or delete a face item, separa- Type from the drop-down list:
tions are usually added or deleted with them.

• Click Move Up to move the currently Item Type Special Behaviors
selected item up one position, switching Blank Area Creates a solid, flat surface.
places with the item directly above. Horizontal Creates a group of identical,
Layout side-by-side items sepa-
• Click Move Down to move the currently rated by vertical separa-
selected item down one position, switch- tions.
ing places with the item directly below. Vertical Layout Creates a group of identical,
• When the selected face item is part of a stacked items separated by
“Layout - Horizontal”, the Move Left horizontal separations.
and/or Move Right buttons will be avail- False Drawer Assumes the appearance of
and False Dou-
specified the drawer style,
able instead. Click either to have the ble Drawer including hardware.
selected item switch places with its Drawer and As specified.
neighbor. Double Drawer
• Click Split Vertical to divide the selected Cutting Board As specified.
face item into two separate side-by-side Auto Right and Become double doors when
items of the same Item Type and Height. Auto Left Door cabinet width is greater than
A vertical separation is added between 24” (600 mm).
them and together the three new items Left, Right, and As specified, regardless of
have the same Width as the original item. Double Door cabinet width.
Not available for Horizontal or Vertical Door Panel Assumes the appearance of
Layouts, Appliances, Separations, or for the specified door style but
with no hardware.
items 1 1/2” (50 mm) wide or less.
Opening Creates an opening with
• Click Split Horizontal to divide the shelves.
selected face item into two separate items Separation Creates a horizontal rail, or
of the same Item Type and Width, frame piece.
stacked one above the other. A horizontal Appliance Creates an opening with no
separation is added between them and shelves, for which an appli-
together the three new items have the ance can be specified.
same Height as the original item. Not • Specify the selected face item’s Item
available for Horizontal or Vertical Lay- Height. Fractional values are supported
outs, Appliances, Separations, or for to 1/16th of an inch (1 mm). For doors
items 1 1/2” (51 mm) tall or less.
and drawers, this is the height of the
opening rather than the item front height.

634
