Chief Architect X10 Reference Manual

• Face items identified as “Horizontal Lay-
• Click the Select Cabinet Face Item
button, then click on an item on the front out” in the list on the left cannot be
of the cabinet in the preview to select that selected in the preview.
item. The selected face item is high- • The cabinet Label displays below the
lighted in grey. preview pane. See “Cabinet Labels” on
page 617.
• When the Mouse-Orbit Camera
mode is active, you can right-click on a
front item to select it.

DOOR/DRAWER Panel

The settings on the DOOR/DRAWER panel Specification dialogs, which allow you to
allow you to control the appearance of the customize the door, drawer, or panel style
selected cabinet’s doors, drawers and and hardware for individual cabinet face
hardware. items. See “Front/Sides/Back Panel” on page
632.
Similar settings are also found in the Door,
Drawer, and Side Panel Face Item

636
