Chief Architect X10 Reference Manual

• Front Pilaster - Select the default front defined. See “Stretch Planes and Zones”
pilaster, a pilaster from the library, or on page 965.
None. • Check Retain Toe Kick to place a toe
• Corner Pilaster - Select the default cor- kick under the cabinet. When unchecked,
ner pilaster, a pilaster from the library, or the toe kick is suppressed.
None. Specifying a corner pilaster auto- Specify the characteristics of the
matically creates a flat corner surface and 3 selected cabinet’s Panels. You can
overrides the Flat Corner setting on the specify whether a panel is applied or inset by
General Panel. Does not apply to Corner selecting the desired Item Type. See “Front/
cabinets with Diagonal Doors selected.
Sides/Back Panel” on page 632.
• Specify the Width of the selected cabi- • Choose “Use Default” or select a Slab,
net’s pilasters. This value applies to both Framed, or Library Panel Style from the
front and corner pilasters.
drop-down list.
• Check Extend to Bottom to extend front • Click the Library button to select a panel
and corner pilasters to the bottom of the style from the Library Browser. Cabinet
toe kick. When this is unchecked, pilas- doors are typically used, although draw-
ters stop at the top of the toe kick.
ers can be used, as well. See “Select
2 Specify Cabinet Feet for the selected Library Object Dialog” on page 940.
Standard or Bow Front cabinet(s). • Specify the selected panel’s Thickness.
Select the Default cabinet foot, a cabinet foot
from the Library, or None. Not available for 4 Specify additional characteristics of the
wall cabinets. selected cabinet’s Side Panels.
• Specify the Width Offset, which is the • Check Full Size Panel to apply a single
offset of the cabinet feet relative to the panel to the entire side. When unchecked,
sides of the cabinet box. the panel uses the same Style and Over-
lap values as the front. If the cabinet has
• Specify the Depth Offset, which is the multiple levels of doors on its front, the
offset of the cabinet feet relative to the side will have matching panels.
front and back of the cabinet box.
• Check Full Overlay to extend Left and
• Check Always Present to place cabinet Right Side Panels to the outer surfaces of
feet under the selected cabinet regardless the cabinet’s front and back, including
of where it is located. When checked, any any doors, panels, or finishes that may be
adjacent cabinet edges will display feet as present.
well. When unchecked, the cabinet will
only receive feet along its outside edge if • Check Extend to Bottom to extend pan-
it is an end cabinet. els on the Left, Right, or Back Sides to
the bottom of the cabinet, including the
• Check Stretch to Fit to resize the cabinet toe kick.
feet so that they extend from each corner
to the midpoint of each edge. Only affects 5 A preview of the selected cabinet
cabinet foot symbols with stretch planes displays on the right side of the panel.

640
