Chief Architect X10 Reference Manual

• Specify the to Top distance, measured Layer Panel
from the Elevation Reference to the top
of the shelf or partition. For information about the settings on this
panel, see “Layer Panel” on page 195.
• Specify the to Bottom distance, mea-
sured from the Elevation Reference to the Materials Panel
bottom of the shelf or partition.
The settings on the MATERIALS panel affect
2 Check Include in Schedule to include the appearance of the selected object in 3D
the selected cabinet(s) in the Cabinet
Schedule. See “The Schedule Tools” on page views. For information about these settings,
see “Materials Panel” on page 1017.
668.
3 A preview of the selected object Label Panel
displays on the right side of the panel.
See “Dialog Preview Panes” on page 42. Shelf and Partition labels display in floor
plan and cross section/elevation views when
Fill Style Panel the “Cabinets, Labels” layer is turned on and
use the Text Style assigned to that layer. The
The settings on the FILL STYLE panel affect Automatic Labels for Shelves and Partitions
the appearance of the selected object in floor re blank, but you can specify custom labels
plan view. For information about these See “Cabinet Labels” on page 617.
settings, see “Fill Style Panel” on page 315.
For more information about the settings on
this panel, see “Label Panel” on page 682.
Moldings Panel
The settings on the MOLDINGS panel allow Object Information Panel
you to apply molding to the selected object. The information entered on the OBJECT
For information about these settings, see INFORMATION panel can be used in Cabinet
“Moldings Panel” on page 641.
Schedules and the materials list. For more
information, see “Object Information Panel”
on page 685.

Custom Countertop Specification Dialog

Select a custom countertop and click the Custom Countertop Specification
the Open Object edit button to open dialog.

644
