Chief Architect X10 Reference Manual

1 Shelf Management - Specify how • Specify the total Number of Shelves in
shelves in the selected face item are the selected door or opening front item.
created. • Select a Shelf from the drop-down list to
• By default, cabinet doors and openings customize its settings. To edit all shelves
receive Automatic cabinet shelves. The at once, choose “All Shelves”.
number of shelves, shelf type, thickness,
spacing, and depth display below. Note: If “All Shelves” is selected after
• Select the Manual radio button to specify changes are made to an individual shelf, “No
the shelving for the selected door or Change” may display in the settings that fol-
opening. If the cabinet is resized after low.
shelving has been manually edited, the • Click the Library button to select a shelf,
specifications are maintained, but all storage, or organization object from the
shelves may not display in all situations.
Library Browser. See “Inserted Objects”
2 The Automatic Settings display here on page 940.
for reference only. • Click the Clear button to restore the

3 The Manual Shelf Specification default shelf style.
settings are available when Manual is
selected, above.

642
