Chief Architect X10 Reference Manual

Reference to the bottom of the counter- countertop. For information about these
top. settings, see “Moldings Panel” on page 641.

4 A preview of the selected cabinet Line Style Panel
displays on the right side of the panel.
See “Dialog Preview Panes” on page 42. For information about the settings on this
panel, see “Line Style Panel” on page 301.
Polyline Panel
Fill Style Panel
The POLYLINE panel states the length of the
countertop’s Perimeter, its Area, and its The settings on the FILL STYLE panel affect
Volume. See “Polyline Panel” on page 314. the appearance of the selected countertop in
If the selected countertop has any Holes, they floor plan view. For information about these
will be subtracted from the Area and settings, see “Fill Style Panel” on page 315.
Volume values. See “Custom Counter
Holes” on page 609. Materials Panel
The settings on the MATERIALS panel affect
Selected Line/Arc Panel the appearance of the selected countertop in
The SELECTED LINE panel is available when 3D views. For information about these
the selected edge is a line as opposed to an settings, see “Materials Panel” on page 1017.
arc. For more information, see “Line Panel”
on page 300. Label Panel
The SELECTED ARC panel is available when Custom Countertop labels display in floor
the selected edge has been converted to an plan and cross section/elevation views when
arc. For more information, see “Arc Panel” the “Polylines 3D, Labels” layer is turned on
on page 309. and use the Text Style assigned to that layer.
The Automatic Label for countertops is
See, too, “Selected Edge” on page 214 and blank, but you can specify a custom label.
“Change Line/Arc” on page 260. See “Cabinet Labels” on page 617.

Moldings Panel For information about the settings on this
panel, see “Label Panel” on page 682.
The settings on the MOLDINGS panel allow
you to apply an edge profile to the selected

Cabinet Schedules
The Cabinet Schedule tool allows display schedule numbers. See “Schedules
you to produce customizable cabinet and Object Labels” on page 667.
schedules as well as cabinet labels that

646
