Schedule Specification Dialog

specified floor. Select that room from the colored lines. When this is unchecked,
Include Objects from Room drop-down lines are black and 3D plant previews are
list. See “Create Schedule from Room” shown in grayscale.
on page 669. • C h e c k Scale Images to display object
• When a Framing Schedule is placed in a previews at the same relative scale. When
Wall Detail or Truss Detail, the Only unchecked, each preview fills its cell to
Include Objects from this Detail check the extent possible.
box is available. Uncheck this to include • C h e c k Show Opening Indicators to
objects from throughout the plan. When show opening indicator symbols in 3D
checked, only objects present in the cur- Elevation previews for doors, windows,
rent view are listed. and cabinets.
• Uncheck Group Similar Objects to list • C h e c k Show Casing, Lintel, Sill to
all objects in their own row, even when include these items in 3D Elevations and
they share all attributes. When this is 3D Perspectives in the selected Window
unchecked, objects that share the same Schedule. For doors, the option is Show
attributes are counted in a single row. See Casing, Sill.
“Columns and Quantity” on page 672.
• C h e c k Show Treatments, Shutters to
• If the selected schedule is a layout table, include these items in 3D Elevations and
specify the Minimum Rows that it dis- 3D Perspectives in the selected Window
plays, regardless of its actual content. Schedule. For doors, the option is Show
3 Display Options - Shutters.
5 Specify which Columns are included in
• Uncheck Display Column Headings to the selected schedule. The columns that
hide the selected schedule’s Heading row. are available will vary depending on the type
When this is checked, each column has a of schedule selected. See “Columns and
heading at the top. Objects to Include” on page 672.
• Uncheck Display Totals Row to suppress • An alphabetical list of all Available Col-
the bottom row stating the total area for umns for the selected schedule type dis-
all objects in the selected schedule. Only plays on the left.
available when one or more “Area” col- • Select one or more names in the list, then
umns are included in the selected Door, click the Add button to add them to the
Window, or Room Schedule. Columns to Include list on the right. See
4 The Object Preview Options affect the “Shift and Ctrl Select” on page 216.
appearance of previews in the 2D • You can also double-click on an item in
Symbol, 3D Elevation, and 3D Perspective the list to add it to the Columns to Include
Columns, when included in the schedule. See list on the right.
“Object Previews” on page 672.
• A list of the Columns to Include in the
• Check Show Color to draw 3D Elevation selected schedule displays on the right.
and 3D Perspective object previews using The top-to bottom order in this list corre-

677
