Chief Architect X10 Reference Manual

a firebox or a hearth. Fireplace foundations
places present on Floor 1. See “Building
a Foundation” on page 692. can be edited or deleted as needed. A firebox
and hearth can be added in the Fireplace
Fireplace foundations are the same material Specification dialog.
type as the original fireplace, but do not have

Fireplace Specification Dialog

Select a masonry fireplace and click but all objects in selection group must be
the Open Object edit button to either placed in a wall or free-standing.
display the Fireplace Specification dialog. Dimensions in this dialog here must be
Multiple fireplaces can be group-selected,
entered in whole inches. Fractions and
decimals are not accepted.
General Panel

1 Specify the Size and Position of the • Specify the Hearth Depth. This is mea-
selected fireplace and its hearth. sured from the front of the fireplace out
• Specify the Height, Width, and Depth of into the room. To eliminate the hearth
the fireplace. altogether, enter a zero for this value.

708
