Chief Architect X10 Reference Manual

General Panel

1 Type - Specify whether the selected Fill Style Panel
object is a Round Pier or Square Pad.
The settings on the FILL STYLE panel affect
2 Specify the Size and Position of the the selected pier or pad’s appearance in floor
selected pier or pad. plan view. For information about these
• Specify the Top Height and Bottom settings, see “Fill Style Panel” on page 315.
Height, as measured from zero.
Materials Panel
• Specify the selected pier or pad’s Width.
For information about the settings on this
Layer Panel panel, see “Materials Panel” on page 1017.

For information about the settings on this
panel, see “Layer Panel” on page 195.

Fireplaces

A masonry fireplace can be placed in A selection of prefabricated metal fireplaces
or away from a wall by selecting is also available from the Architectural Core
Build> Fireplace and then clicking in the Catalog. These can be framed in with
drawing area. standard walls. See “The Library” on page
• If created in a wall, it is considered a wall 921.
opening and can be moved or resized like The display of fireplaces is controlled in the
a window or door. Layer Display Options dialog. See “Layer
• If created away from a wall, it moves and Display Options Dialog” on page 190.
resizes similar to a cabinet.

706
