Chief Architect X10 Reference Manual

• Open a saved view in which the Annota- You can view and modify the currently active
tion Set was previously active. Saved Defaults in the Active Defaults
dialog. You can also save the current defaults
Using Active Defaults as an Annotation Set for future use, if you
wish. See “Active Defaults Dialog” on page
If a particular Annotation Set is active and 91.
you switch one of its Saved Defaults to a
different Saved Default, the Annotation Set Creating Annotation Sets
will no longer be considered active and
“Using Active Defaults” will display in the There are two ways to create a new
Active Annotation Set Control drop-down. Annotation Set:
This is not a problem: it simply means that • Click either the New or the Copy button
you aren’t using all of the defaults that you in the Annotation Sets dialog.
may have set up for a specific purpose.
• Click the Save Current Active Defaults
button in the Active Defaults dialog.

Annotation Sets Dialog

The Annotation Sets dialog lists the Select “Annotation Sets” and click the Edit
Annotation Sets available in the button. See “Default Settings” on page 86.
current plan file and lets you add, remove, You can also open this dialog by clicking the
edit, and save them.
Annotation Sets button, which you can
To open the Annotation Sets dialog, select
add to your toolbars. See “To add a button to
Edit> Default Settings from the menu. a toolbar” on page 143.

94
