Multiple Saved Defaults

tiple selected Saved Defaults can be cop- • Click the Select All button to select all
ied as well. Saved Defaults in the list.
•In the New Default Name dialog, which • Click the Clear All button to deselect all
opens when you click Copy, type a short, Saved Defaults in the list.
descriptive, unique name for the new The Currently Active Saved Defaults
saved default. The Defaults dialog for the 2 for the selected object type displays and
new Saved Default opens next. Make any can be changed here.
needed changes to its settings and click
OK. • Select a Saved Default from the drop-
down list to make it active when you click
• Click the Rename button to open the OK.
Rename Current Default dialog and type
a new name for the current Saved Default. •Click the Edit button to open the Defaults
Names are case-sensitive and must be dialog for the Saved Default selected in
unique. the drop-down list.
• Click the Delete button to remove the
selected Saved Default from the list. Note: if you click Cancel or press Esc in the
Saved Defaults assigned to an Annotation Saved Defaults dialog after editing, renaming,
Set in the current file cannot be deleted, or copying a Saved Default, your changes will
nor can a Saved Dimension Default used not be retained.
by a dimension line. See “Dimension Line Click Cancel to close the dialog without
Specification Dialog” on page 481.
retaining any of your changes. Any newly
added Saved Defaults will not be retained.
Active Defaults Dialog

You can view and modify the defaults
that are currently active by clicking Saved Defaults can also be managed in
the Active Defaults toolbar button to open the Annotation Sets dialog, and can be
the Active Defaults dialog. This dialog can grouped into Annotation Sets for specific
also be accessed via the Default Settings drawing tasks.
dialog.
